Your Lever RM1-1662-000CN is #3

HP parts picture diagram for RC1-4322-000CN, RM1-1662-000CN, RM1-1756-000CN
Picture Items

       Description (click to view price and order)

    Paper feed assembly - Includes metal plate, pickup drive solenoid, drive gears and media sensor - Part: RM1-1756-000CN

    Lower cover - Covers lower right corner of Electrostatic Transfer Belt (ETB) area - Part: RC1-4322-000CN

    Electrostatic Transfer Belt (ETB) lever assembly - Right top of ETB clips into this - Part: RM1-1662-000CN
