| C8117A-Absorber |
Absorber - Ink service station (ISS) bottom absorber foam - absorbs ink during the cleaning process. Service station absorber (sponge) - soaks up used ink during cartridge cleaning. Works as sled filters. |
| C8117A-AC_Adapter |
AC Adapter - Power supply module or adapter - one end for connecting to the printer and other end to the power cord, or your ac adapter may have the pwr cord attached. |
| C8117A-Actuator |
Actuator - Actuating unit. this part usually causes the carriage assembly to stalls on the left side of the printer, verify that the clutch actuator arm (slider arm). |
| C8117A-Arm_Delivery |
Arm Delivery - Paper sensing arm - for 'paper out' or delivering paper sensing arm |
| C8117A-Arm_Door |
Arm Door - Carriage access door sensor arm |
| C8117A-Arm_Pickup |
Arm Pick Up - Paper detection arm - for registration plate on picking up paper |
| C8117A-Arm_Plate |
Arm Plate - Lever arm - used to lift the pressure plate lifter |
| C8117A-Arm_Sensing |
Arm Sensing - Arm assembly senses paper in bottom tray |
| C8117A-Arm_Tension |
Arm Tension - Tension arm - maintains tension on carriage belt |
| C8116-67001 |
Base - Base assembly for HP Business InkJet 3000 Series |
| C8116-67056 |
Bearing - Paper feeder roller |
| C8116-67005 |
Belt - A-size carriage belt |
| C8117A-Belt_ADF |
Belt ADF - Transport belt motor - provides the drive to transport paper through the ADF unit. this belt goes in the ADF assembly drive unit |
| C8117A-Belt_Carriage |
Belt Carriage - Carriage belt - moves the carriage assembly across the carriage rod |
| C8117A-Belt_Duplex |
Belt Duplex - Duplex timing belt - small belt that goes on the duplexer unit |
| C8117A-Belt_Paper |
Belt Paper - Paper drive belt (usually a small belt) - this belt attaches to a gear which is driven by the paper drive motor assembly. |
| C8117A-Bezel |
Bezel - Front panel overlay (bezel) - (english) control panel bezel - frame around display and control panel |
| C8116-67055 |
Blower Assembly - Blower-Vacuum assembly |
| C8117A-Bracket_Left |
Bracket Left - Left bracket - carriage rod adjustment bracket (left) |
| C8117A-Bracket_Right |
Bracket Right - Right bracket - carriage rod adjustment bracket (right) |
| C8117A-Bracket_Tension |
Bracket Tension - Belt tension bracket - holds the carriage belt idler pulley |
| 5063-1256 |
Cable - IEEE-1284 Bi-Tronics parallel cable - DB-25 (M) connector (type A) to 36-pin Centronics (M) connector (type B) - 2.0m (6.6ft) long |
| C2950A |
Cable - IEEE 1284 Bi-Tronics parallel cable - DB-25 (M) connector (type A) to 36-pin Centronics (M) connector (type B) - 2.0m (6.6ft) long |
| C2951A |
Cable - IEEE-1284 Bi-Tronics parallel cable - DB-25 (M) connector (type A) to 36 pin Centronics (M) connector (type B) - 3.0m (9.8ft) long |
| C6518A |
Cable - Universal Serial Bus (USB) interface cable - Type 'A' connector to type 'B' connector - 2.0m (6.6ft) long |
| C8116-67037 |
Cable - Power supply harness |
| C8116-67042 |
Cable - Trailing cable for HP Business InkJet 3000 Series |
| C8117A-Cable_Carriage |
Cable Carriage - Cable assembly which connects the main logic board to the carriage motor |
| C8117A-Cable_Interface |
Cable Interface - Parallel cable - connects from your printer to computer via your parallel port. |
| C8117A-Cable_Mchnsm |
Cable Mechanism - Cable assembly which connects the main logic board to the print mechanism |
| C8117A-Cable_Panel |
Cable Panel - Cable Panel assembly - includes ribbon cable this is the cable that connects to the control panel or display. |
| C8117A-Cable_USB |
Cable USB - This interface cable is the standard 2.0 usb cable that connects to your printer and computer for printing. |
| C8117A-Cam |
Cam - Drawer cam - short, spring loaded lever attached to the paper tray frame - used to draw input tray into position |
| C8117A-Cap_Lifter |
Cap Lifter - These lifter caps hold the pressure plate lifter and the kicker spring in place. |
| C8116-67043 |
Carriage - Carriage assembly |
| C8117A-Carriage_Assy |
Carriage Assembly - Ink cartridge carriage assembly - includes carriage, felt, felt retainers, ink cartridge latches, trailing cable, pc board, belt attachment hardware, and slider. |
| C8117A-Carriage_Base |
Carriage Base - Carriage base or pre-loader assembly - mounted to bottom of carriage base |
| C8117A-Carriage_Belt |
Carriage Belt - Carriage drive belt, this belt is attached to the carriage and carriage motor, it moves the carriage side to side while priting. |
| C8117A-Carriage_Cable |
Carriage Cable - Flex circuit cable which connects the head driver board to the carriage assembly. in some units it is also known as the trailing cable, this cable moves along with the carriage unit (side to side). |
| C8117A-Carriage_Latch |
Carriage Latch - A-arm latch - retains latch over the printheads on the carriage |
| C8117A-Carriage_Latch_CVR |
Carriage Latch Cover - The carriage latch is used to keep the cartridge(s) in place. this latch(s) hold the cartridge(s) in place while carriage is printing or idle. |
| C8117A-Carriage_Motor |
Carriage Motor - Carriage motor moves the carriage unit side to side. the carriage belt goes arround this motor, which controls carriage movement. |
| C8117A-Carriage_Only |
Carriage Only - Carriage only - includes carriage, felt, felt retainers, ink cartridge latches - does not include trailing cable, pc board, belt attachment hardware, or slider (for complete carriage unit, please see carriage assembly). |
| C8117A-Carriage_PC_BRD |
Carriage PC Board - This pc board attaches on the carriage, it is usually a small pc board that has carrage cable attached to it. |
| C4804A |
Cartridge - No.12 Cyan ink cartridge (holds 55ml of ink) |
| C4805A |
Cartridge - No.12 Magenta ink cartridge (holds 55ml of ink) |
| C4806A |
Cartridge - No.12 Yellow ink cartridge (holds 55ml of ink) |
| C4820-80100 |
Cartridge - Ink system return kit (box and instructions) - For returning printheads, printhead cleaner, and ink cartridges |
| C4844A |
Cartridge - HP 10 High Capacity Black Ink Cartridge - 69ml, prints approximately 1400 pages at 5% printing density (USA) |
| C4844AA |
Cartridge - No.10 high capacity Black ink cartridge (holds 69ml of ink) - Prints approximately 1400 pages at 5% printing density (Asia/Pacific) |
| C4844AE |
Cartridge - No.10 high capacity Black ink cartridge (holds 69ml of ink) - Prints approximately 1400 pages at 5% printing density (Europe) |
| C4844AL |
Cartridge - No.10 high capacity Black ink cartridge (holds 69ml of ink) - Prints approximately 1400 pages at 5% printing density (Latin America) |
| C8117A-Chassis |
Chassis - Chassis assembly - the large plastic item that forms the base of the print mechanism |
| C8117A-Clutch_Feed |
Clutch Feed - Clutch unit resposible for unit picking up paper from the pick up unit. |
| C8117A-Control_Panel |
Control Panel - Control panel assembly - control buttons and display on top front of the unit. |
| C8116-67003 |
Cover - Left-side end cap |
| C8116-67004 |
Cover - Rear cover for HP Business InkJet 3000 Series |
| C8116-67007 |
Cover - Left rail cover |
| C8116-67008 |
Cover - Right rail cover |
| C8116-67013 |
Cover - Main cover for HP Business InkJet 3000 Series |
| C8116-67014 |
Cover - Right-side end cap |
| C8116-67016 |
Cover - Front keypad cover |
| C8116-67030 |
Cover - DIMM cover for HP Business InkJet 3000 Series |
| C8116-67031 |
Cover - Formatter cover |
| C8117A-Cover_Back |
Cover Back - Back cover of printer, it is usually removed to clear paper jams. |
| C8117A-Cover_Cartridge |
Cover Cartridge - This is the cover/ door that is opened to remove the cartridge(s) - usually, when this door opens the carriage moves. |
| C8117A-Cover_Main |
Cover Main - This is the main cover of the printer. it is the biggest piece of plastic the printer is made off. |
| C8117A-Deflector |
Deflector - Paper deflector - guides paper out of dispose assembly - through the internal paper path cover. paper deflector - directs paper from the media chassis to the print section of the printer chassis assembly |
| C8117A-Display |
Display - Status led display (LCD display assembly). |
| C8116-67002 |
Door - Top/front main access door assembly |
| C8116-67012 |
Door - Main access door - Installs on the main cover |
| C8117A-Door_Carriage |
Door Carriage - Main front access door - covers the top of the printer and provide access to the carriage when open. |
| C8117A-Door_Cartridge |
Door Cartridge - Small front access door (drop down door) - for accessing print cartridge window - for print cartridge access door. |
| C8117A-Door_Rear |
Door Rear - Rear cleanout door assembly - rear paper jam clean out door assembly. |
| C8117A-Drive_Assy |
Drive Assembly - Paper drive roller kit - includes roller assembly, bushings, gear on roller, transmission gear kit, encoder disc, end thrust (axial) spring. |
| C8117A-Duplexer |
Duplexer - Auto duplexer assembly - provides double sided printing capability |
| C8228A |
Duplexer - Business InkJet 3000 series auto duplex unit |
| C8116-67027 |
Enclosure - Engine enclosure |
| C8116-67028 |
Enclosure - Formatter enclosure |
| C8116-67029 |
Enclosure - EIO enclosure for HP Business InkJet 3000 Series |
| C8117A-Encoder |
Encoder - Encoder spring - provides tension for encoder strip |
| C8117A-Encoder_Disk |
Encoder Disk - Disk encoder - helps to provide position information of the paper |
| C8117A-Encoder_Strip |
Encoder Strip - Encoder strip - carriage position sensor reference |
| C8117A-Extender_Input |
Extender Input - Tray extension assembly (stopper) - tray with a paper stop on the input tray - extends to accomodate different media lenths |
| C8117A-Extender_Output |
Extender Output - Paper exit tray extension |
| C8117A-Fan_PC_BRD |
Fan PC Board - Fan to cool power supply unit |
| C8117A-Fan_Vaccum |
Fan Vaccum - Vacuum fan assembly |
| C8117A-Feed_Rollers |
Feed Rollers - Feed roller assembly - includes frame asembly, shaft with rollers, and encoder disk |
| C8116-67052 |
Feeder - Paper feeder - Includes encoder |
| C3828A |
Film - Film (Transparency) for OfficeJet R65 Series, PhotoSmart P1000, PhotoSmart P1100, OfficeJet G55 Series Transparency Film 200 SHEETS. |
| C3832A |
Film - Premium InkJet transparency film - A4 size (21.0cm x 29.7cm) - 20 sheets per package |
| C3834A |
Film - Film (Transparency) for DeskJet 1600 Series, DeskJet 2000 Series, DeskJet 800 Series, DeskJet 600 Series |
| C3835A |
Film - Film (Transparency) for DeskJet 1200 Series, DeskJet 500 Series, DeskJet 550C Series, DeskJet 850 Series |
| C8117A-Flag_Paper |
Flag Paper - OOPS flag - out of paper sensor |
| C8116-67023 |
Foot - Rubber foot - Replacement rubber foot for the bottom of the printer (four used) |
| C8117A-Formatter |
Formatter - Formatter board assembly, this board communicates with your computer device and has MAC port connector. |
| C8117A-Front_Panel |
Front Panel - Front panel assembly - includes lcd and actuator buttons |
| C8117A-Gear_Assy |
Gear Assembly - ADF gear assembly driven by ADF main motor |
| C8117A-Gear_Cluster |
Gear Cluster - Cluster gear, large gear on service station |
| C8117A-Gear_Double |
Gear Double - Transfer gear - has double gear attached on service station |
| C8117A-Gear_Main |
Gear Main - Paper pickup drive assembly - gear assembly located on right side of paper pickup assembly. gear moves the main paper pick up roller. |
| C8117A-Gear_Station |
Gear Station - Gears on shaft of spittoon station |
| C8117A-Glass_Assy |
Glass Assembly - Main top copier glass assembly. |
| C8116-67051 |
Guide - Front paper feeder guide |
| C8116-67053 |
Guide - Lower paper feeder guide |
| C8117A-Guide_Paper |
Guide Paper - Upper paper guide - spring loaded flat plate that presses the media against the top of the feed roller assembly - caution: this part can easily be broken |
| C8116-67054 |
Heater - Post heater and aerosol system |
| C8117A-Holder |
Holder - Ink cartridge holder - located on carriage unit, holder secures ink cartridge in place. |
| C8117A-Idler |
Idler - Scanner belt idler assembly - maintains scannter belt tension. |
| C8116-67049 |
Ink Delivery System - Replaceable ink delivery system |
| C8117A-Ink_DLVRY |
Ink Delivery System - RIDS assembly - replaceable ink delivery system - transports ink from ink supply station to carriage assembly |
| C8116-67048 |
Ink Supply Station - Ink supply station |
| C8117A-Ink_Supply_Station |
Ink Supply Station - Ink supply service station (iss) assembly |
| C8116-67015 |
Keypad - Keypad assembly |
| Q2550A |
Label - Label for DeskJet 660 Series, DeskJet 300, DeskJet 420C, DeskJet 1220 Series |
| Q2551A |
Label - Label for PSC 1118 Series, PSC 1200 Series All-in-One, PSC 1200 Series All in One, HP PSC 1210 All-in-One |
| Q2587A |
Label - White labels - 2.5cm (1.0in) x 6.6cm (2.6in) - 30 labels per sheet, 25 sheets per box |
| Q2588A |
Label - Label for OfficeJet 6100 Series, Digital Copier Printer 410, PSC 1110 Series All in One, PSC 1118 Series |
| Q2589A |
Label - Label for LaserJet 2400 Series, PhotoSmart 7830 Series, HP Photosmart 7850 Photo Series, Photosmart 7850 Photo Printer |
| Q2590A |
Label - Label for PSC 900 Series All in One, PhotoSmart 100 Printer, PhotoSmart 130 Series, Color LaserJet 9500 Series |
| Q2591A |
Label - Label for PSC 1200 Series All-in-One, PSC 1200 Series All in One, HP PSC 1210 All-in-One, OfficeJet 5110 Series All-in-One |
| Q2592A |
Label - Label for OfficeJet D Series All in One, OfficeJet 7100 Series All in One, OfficeJet V40 Series, PSC 900 Series All-in-One |
| Q2593A |
Label - Label for PSC 1200 Series All in One, Color LaserJet 5500 Series, OfficeJet D Series All-in-One, OfficeJet D Series All in One |
| Q2594A |
Label - White address labels - 8.4cm (3.3in) x 10cm (4in) - 6 labels per sheet, 100 sheets per box |
| C4287A |
Memory - 4MB flash DIMM memory - Font storage device |
| C7846A |
Memory - 64MB SDRAM - 100MHz synchronous DRAM - DIMM package |
| C9121A |
Memory - 128MB, 100-pin SDRAM DIMM memory module |
| Q1887A |
Memory - 64MB, 100-pin SDRAM DIMM memory module |
| Q7708AX |
Memory - 64MB SDRAM - 100MHz synchronous DRAM - DIMM package |
| Q7709AX |
Memory - 133 MHz 128MB, 100-pin SDRAM DIMM memory module Synchronous DRAM DIMM |
| C8117A-Motor_Carriage |
Motor Carriage - Carriage motor - motor that drives the carriage assembly |
| C8117A-Motor_Scanner |
Motor Scanner - Scanner unit motor - drives the scanner unit to scan documents to be copied, fax, or scanned. |
| C8117A-MTR_Srvce_Station |
Motor Service Station - Service station stepper motor (does not include cable) - moves the rack vertically in the service station assembly |
| 6040-0990 |
Oil - Special lubricating oil - For carriage slider rod surface - (5cc oil) |
| C8116-67050 |
Overdrive Assembly - Overdrive assembly |
| C8117A-Overlay |
Overlay - Overlay unit which covers the control button or display (english overlay only), control panel or display sold seperately. |
| C8117A-Pad_Tray |
Pad Tray - Pad separator - (located on tray) assembled from plastic and rubber components; to help in separating sheet of media during printing |
| 51634Y |
Paper - HP Premium Inkjet Paper - A size (8.5 x 11-inches) - 200 sheets |
| 51634Z |
Paper - InkJet non-glossy LX paper - A4 size (21.0cm x 29.7cm) - 200 sheets per package |
| C1853A |
Paper - Premium InkJet Heavyweight Paper - A4 size (21.0cm x 29.7cm) - Coated on both sides - 100 sheets |
| C6817A |
Paper - Brochure and flyer paper - Glossy on both sides - A size (8.5 x 11-inches), 98 brightness - 50 sheets |
| C6818A |
Paper - Paper (Glossy) for OfficeJet 5615 Series, OfficeJet 5605 Series, OfficeJet 6310 All-in-One, OfficeJet 6301 Series |
| C6831A |
Paper - HP Premium Plus Glossy Photo Paper - A size (8.5 x 11-inches) - 20 sheets |
| C6832A |
Paper - Paper (Glossy) for DeskJet F4180 Series, HP Deskjet F4100 All-in-One printer series, DeskJet F4140 Series, DeskJet F4135 All-In-One |
| C6951A |
Paper - Paper (Matte) for PSC 1400 Series, OfficeJet 5610 Series, OfficeJet 5605 Series, OfficeJet 5615 Series |
| C6955A |
Paper - Professional Brochure and Flyer Paper (Matte) - A size (8.5 x 11-inches) - 50 sheets |
| C6983A |
Paper - Photo quality InkJet paper - With two sided semi-gloss finish - A size (8.5 x 11-inches) - 25 sheets per package |
| C6984A |
Paper - Paper (InkJet Photo) for DeskJet 3400 Series, PSC 2210 Series All in One, DeskJet 3800 Series, DeskJet 3325 Series |
| C7006A |
Paper - Paper (InkJet Photo) for DeskJet 6620 Series, PhotoSmart 100 Printer, PSC 900 Series All in One, PSC 900 Series All-in-One |
| C7007A |
Paper - Photo Quality InkJet Paper (Matte) - With two sided matte finish - A size (8.5 x 11-inches) - 100 sheets |
| C7013A |
Paper - Colorfast photo paper - A size (8.5 x 11-inches) - 20 sheets per package |
| C7014A |
Paper - Paper (Photo) for DeskJet 656 Series, DeskJet 3400 Series, DeskJet 3325 Series, DeskJet 3800 Series |
| Q1787A |
Paper - Linen Half-fold Greeting Card Paper (Ivory) - A size (8.5 x 11-inches) - 20 cards |
| Q1788A |
Paper - Linen Half-fold Greeting Card Paper (White) - A size (8.5 x 11-inches) - 20 cards |
| Q1934A |
Paper - Paper (Matte) for DeskJet 1220 Series, DeskJet 1200 Series, DesignJet 1055 Series, OfficeJet G55 Series |
| Q1935A |
Paper - Paper (Glossy) for Photosmart 475 series compact photo printer, PhotoSmart A430 Series, PhotoSmart D71XX Series, PhotoSmart D73XX Series |
| Q1951A |
Paper - Paper (Glossy) for PhotoSmart D71XX Series, PhotoSmart D73XX Series, HP Photosmart D7300 series, PhotoSmart D5155 Series |
| Q1969A |
Paper - Paper (Glossy) for DeskJet 660 Series, DeskJet 300, DeskJet 420C, DeskJet 1220 Series |
| Q1971A |
Paper - Paper (Photo) for DeskJet 660 Series, DeskJet 300, DeskJet 420C, DeskJet 1220 Series |
| Q1976A |
Paper - Paper (Semi-Glossy) for DeskJet 660 Series, DeskJet 300, DeskJet 420C, DeskJet 1220 Series |
| Q1977A |
Paper - Paper (Glossy) for Deskjet 460 Series, OfficeJet Pro K550 Series, Business Inkjet 2800 Series, DeskJet 9800 |
| Q1977AC |
Paper - Premium Plus Photo Paper (High Gloss) - 10.2cm (4in) x 15.2cm (6in), finished size - 10.2cm (4in) x 16.5cm (6.5in), with tab - 20 sheets (Canada) |
| Q1978A |
Paper - Premium Plus Photo Paper (High Gloss) - 10.2cm (4in) x 15.2cm (6in), finished size - 10.2cm (4in) x 16.5cm (6.5in), with tab - 60 sheets |
| Q1978AC |
Paper - Premium Plus Photo Paper (High Gloss) - 10.2cm (4in) x 15.2cm (6in), finished size - 10.2cm (4in) x 16.5cm (6.5in), with tab - 60 sheets (Canada) |
| Q1979A |
Paper - Premium Plus Photo Paper (High Gloss) - 10.0cm (3.9in) x 15.0cm (5.9in), finished size - 10.0cm (3.9in) x 16.3cm (6.4in), with tab - 20 sheets |
| Q1980A |
Paper - Premium Plus Photo Paper (High Gloss) - 10.0cm (3.9in) x 15.0cm (5.9in), finished size - 10.0cm (3.9in) x 16.3cm (6.4in), with tab - 60 sheets |
| Q1987A |
Paper - Paper (Glossy) for OfficeJet G85 Series, OfficeJet K60, OfficeJet K80 Series, PSC 500 Series |
| Q1988A |
Paper - Paper (Glossy) for PhotoSmart 420 Series, HP Photosmart 422 Portable Photo Studio, PhotoSmart 475 Series, Photosmart 475 series compact photo printer |
| Q1989A |
Paper - Paper (Glossy) for PSC 1300 Series All in One, PSC 2300 Series, OfficeJet 6200 Series, OfficeJet 6210 |
| Q1990A |
Paper - Paper (Glossy) for PhotoSmart 325 Series, PhotoSmart 375 Series, OfficeJet 5500 Series All-in-One, OfficeJet 5500 Series All in One |
| Q1991A |
Paper - Paper (Glossy) for PhotoSmart 230 Series, PhotoSmart 245 Series, PSC 2170 Series All-in-One, PSC 2170 Series All in One |
| Q2506A |
Paper - Premium Plus Photo Paper (Satin Matte) - 10.2cm (4in) x 15.2cm (6in) finished size - 10.2cm (4in) x 16.5cm (6.5in) with tab - 60 sheets |
| Q2507A |
Paper - Premium Plus Photo Paper (Satin-matte) - 10.0cm (3.9in) x 15.0cm (5.9in) finished size - 10.0cm (3.9in) x 16.3cm (6.4in) with tab - 60 sheets |
| Q2508A |
Paper - Premium Plus Photo Paper (Satin-Matte) - 10.0cm (3.9in) x 15.0cm (5.9in) finished size - 10.0cm (3.9in) x 16.3cm (6.4in) with tab - 60 sheets |
| Q2525A |
Paper - Paper (Glossy) for Business InkJet 3000 Series, Business InkJet 2230 Series, Business Inkjet 2300 Series, DeskJet 9300 Series |
| Q5431A |
Paper - Paper (Satin) for PhotoSmart A310 Series, PhotoSmart D50XX Series, PhotoSmart A520 Series, HP Photosmart A820 series Compact Photo Printers |
| Q7852A |
Paper - HP Delux Advance Glossy Photo Paper 25 sheets of A size HP Advanced glossy photo paper |
| C8116-60001 |
PC Board - Frmatter board assembly |
| C8116-67032 |
PC Board - Formatter PC board |
| C8116-67033 |
PC Board - Tray 1 interconnect PC board |
| C8116-67044 |
PC Board - Main logic PC board |
| C8116-67064 |
PC Board - Linefeed encoder PC board |
| C8117A-PC_BRD |
PC Board - Ink cartridge carriage assembly pc board - includes carriage pc board only |
| C8117A-PC_BRD_DC |
PC Board DC - Internal power supply board - power cable plugs on this assembly, remove covers to install pc board. |
| C8117A-PC_BRD_Interface |
PC Board Interface - Internal print server lan interface board - plugs into peripheral eio. usefull for networking and multiple users. |
| J3110A |
PC Board Interface - Ethernet 10Base-T (RJ-45) EIO network GENUINE HP JETDIRECT 600N internal print server PC board |
| J3111A |
PC Board Interface - Ethernet 10Base-T/10Base2 and LocalTalk (RJ-45, BNC, LocalTalk) EIO network PCA |
| J3258B |
PC Board Interface - External JetDirect 170X LAN interface module - Interfaces a parallel printer to an ethernet 10Base-T (RJ-45) LAN |
| J3263G |
PC Board Interface - HP JetDirect 300X external print server module (10Base-T and 100Base-TX) - Connects between printer parallel port and LAN network |
| J3264A |
PC Board Interface - HP JetDirect 500X external token ring print server module - Interfaces up to 3 parallel printers to a token ring (DB-9 or RJ-45) LAN |
| J3265G |
PC Board Interface - HP JetDirect 500X external token ring print server module - Interfaces up to 3 parallel printers to an ethernet 10Base-T (RJ-45), 10Base2 (BNC), or 100Base-TX (RJ-45) LAN |
| J4167A |
PC Board Interface - JetDirect 610N token ring LAN interface board - DB-9 and RJ-45 connectors |
| J6035A |
PC Board Interface - HP JetDirect 175X external print server - Has one 4-pin USB connector and one RJ-45 LAN connector - Connects to the printer via the USB port and the network via the LAN port |
| J6038A |
PC Board Interface - HP JetDirect 310X external print server - Fast Ethernet Internet connector for sharing network peripherals with USB ports, in a 10/100 TX LAN environment - Has one USB printer port and one RJ-45 10/100 Base-TX connector |
| J6057AR |
PC Board Interface - JetDirect 615N internal print server (10Base-T and 100Base-TX) LAN interface board - Plugs into peripheral EIO slot - Has a RJ-45 connector - Comes with software on CD-ROM and manual |
| J6057AR |
PC Board Interface - JetDirect 615N internal print server (10Base-T and 100Base-TX) LAN interface board - Plugs into peripheral EIO slot - Has a RJ-45 connector - Comes with software on CD-ROM and manual |
| J6058A |
PC Board Interface - HP JetDirect 680N internal wireless IEEE-802.11b (Wi-Fi) print server - Plugs into peripheral EIO slot |
| J7934G |
PC Board Interface - HP JetDirect 620n internal print server - 10BaseT and 100BaseTX LAN interface board - Plugs into peripheral EIO slot - Has an RJ-45 connector - Comes with software on CD-ROM and manual on CD-ROM |
| C8116-67062 |
Pickup Assembly - Simplexer assembly |
| C8117A-Pinchwheel |
Pinchwheel - Pinch assembly kit - includes all required pinch wheels, pinchwheel mounts and springs |
| 8120-8452 |
Power Cord - Power cord (Black) - 2-wire, 1.8m (6.0ft) long - Has straight (F) C7 receptacle (for 220V in Chile) |
| 8120-8900 |
Power Cord - Power cord (Flint Gray) - 2-wire, 18 AWG, 1.8m (6.0ft) long - Has straight (F) C7 receptacle (for 120V in the United States, Canada, Brazil, Latin America, and Saudi Arabia) Part 8120-8330 is no longer supplied. Please order the replacement, 8120-8900 |
| 8121-0017 |
Power Cord - Power cord (Flint Gray) - 2-wire, 18 AWG, 1.8m (6.0ft) long - Has straight (F) C7 receptacle (for 220V in Korea) |
| 8121-0018 |
Power Cord - Power cord (Flint Gray) - 2-wire, 18 AWG, 1.8m (6.0ft) long - Has straight (F) C7 receptacle (for 220V in Australia and New Zealand) |
| 8121-0019 |
Power Cord - Power cord (Flint Gray) - 18 AWG, 2-conductor, 1.8m (6.0ft) long - Has straight (F) C7 receptacle (For 220VAC in Argentina) |
| 8121-0020 |
Power Cord - Power cord (Flint Gray) - 18 AWG, 2-conductor, 1.8m (6.0ft) long - Has straight (F) C7 receptacle (For 220VAC in South Africa) |
| 8121-0021 |
Power Cord - Power cord (Flint Gray) - 18 AWG, 2-conductor, 1.8m (6.0ft) long - Has straight (F) C7 receptacle (For 100VAC in Japan) |
| 8121-0022 |
Power Cord - Power cord (Flint Gray) - 2-wire, 18 AWG, 1.8m (6.0ft) long - Has straight (F) C7 receptacle (for 240V in the United Kingdom) |
| 8121-0023 |
Power Cord - Power cord (Flint Gray) - 2-wire, 18 AWG, 1.8m (6.0ft) long - Has straight (F) C7 receptacle (for 220V in Europe, Asia Pacific, Germany, Spain, France, Netherlands, Switzerland, Italy, and Portugal) |
| 8121-0024 |
Power Cord - Power cord (Flint Gray) - 2-wire, 18 AWG, 1.8m (6.0ft) long - Has straight (F) C7 receptacle (for 220V in China) |
| 8121-0025 |
Power Cord - Power cord (Flint Gray) - 18 AWG, 2-conductor, 1.8m (6.0ft) long - Has straight (F) C7 receptacle (For 240VAC in India) |
| C8117A-Power_Cord |
Power Cord - Power module power cord- wall outlet cable to power module only. does not include power module. |
| C8117A-Power_MDLE |
Power Module - World wide power module - includes power module and power module to printer cord - does not include outlet to power module cord |
| C8117A-Power_MDLE_Assy |
Power Module Assy - World wide power module - includes power module and power module to printer cord - also, include outlet to power module cord |
| C8116-67034 |
Power Supply - Power supply - Accepts input voltage of 110 or 210 VAC and provides +3.3V, +5V, and +12V DC to the various electronic subsystems |
| C8117A-Power_Supply |
Power Supply - Power supply board (internal pwr supply unit in the office machine). |
| C8117A-Power_Supply_BRD |
Power Supply Board - High voltage power supply board |
| C8117A-Print_Mchnsm |
Print Mechanism - Print mechanism assembly - complete mechanism with carriage movement, paper picking and service station - does not include covers, printer base, print heads, ink cartridges, or any consumables. |
| J3263A |
Print Server - External JetDirect 300X LAN interface module - Interfaces a parallel printer to an ethernet 10Base-T (RJ-45) or 100Base-TX (RJ-45) LAN |
| J3265A |
Print Server - External JetDirect 500X LAN interface module - Interfaces up to 3 parallel printers to an ethernet 10Base-T (RJ-45), 10Base2 (BNC), or 100Base-TX (RJ-45) LAN |
| J6057A |
Print Server - JetDirect 615N internal print server LAN interface board - 10Base-T and 100Base-TX - Plugs into peripheral EIO slot, has RJ-45 connector |
| J7934A |
Print Server - JetDirect 620N Ethernet Print Server, internal print server LAN interface board - 10Base-T and 100Base-TX - Plugs into peripheral EIO slot, has RJ-45 connector. |
| C5023A |
Printhead - No. 12 black printhead |
| C5024A |
Printhead - No. 12 cyan printhead |
| C5025A |
Printhead - No. 12 magenta printhead |
| C5026A |
Printhead - No. 12 yellow printhead |
| C8117A-Pulley |
Pulley - Paper pick up tray motor pulley. |
| C8117A-Repair_InkJet |
Repair Service - Ship your product to us for a small diagnostic fee; and a professional service job. We will contact you with repair total and your diagnostic fee will be waived if unit is repaired. Service warranty is 30days labor and 90days for parts. Extended warranty option is available. |
| C8117A-Rod_Carriage |
Rod Carriage - Carriage rod - shaft that the carriage assembly rides on |
| C8117A-Rod_Scanner |
Rod Scanner - Scanner rod - shaft that the scanner assembly rides on |
| C8116-67019 |
Roller - Pick roller for HP Business InkJet 3000 Series |
| C8116-67020 |
Roller - Separation roller assembly |
| C8117A-Roller_Exit |
Roller Exit - Paper exit rollers - out put assembly. |
| C8117A-Roller_Pickup |
Roller Pickup - Pick up roller assembly for paper bottom tray. Lower feed roller assembly - for lower paper input tray |
| C8117A-Scanner |
Scanner - Copier scanner (optical) assembly - includes scanner assembly only scanner lens assembly (includes the charge coupled device (ccd)) the scanning lamp ADF analog processor board and ADF inverter board - major portion of the ADF main assembly. |
| Q5763-60002 |
Scanner - Scanner - CIS, CMOS, PIC |
| C8117A-Scanner_Assy |
Scanner Assembly - Copier scanner & glass assembly - includes the chassis assembly scanner lens assembly (includes the charge coupled device (ccd)) the scanning lamp ADF analog processor board and ADF inverter board - major portion of the ADF main assembly. |
| C8117A-Scanner_Belt |
Scanner Belt - Scanner belt attaches from the scanner to the scanner motor. |
| C8117A-Scanner_Cable |
Scanner Cable - Flex circuit cable which connects to the scanner assembly. also known as flat cable, this cable moves along with the scanner unit (side to side) as it scans documents. |
| C8117A-Scanner_Motor |
Scanner Motor - Scanner driving motor |
| C8117A-Scanner_Unit |
Scanner Unit - Scanner unit includes the entire scanner base but not the ADF portion. |
| C8116-67024 |
Sensor - Transparency sensor - Detects the use of transparency media - Enables the printer to automatically switch to trasparency printing mode |
| C8117A-Sensor_Exit |
Sensor Exit - Exit media sensor sv |
| C8117A-Sensor_Open |
Sensor Open - Door sensor assembly - open door sensor |
| C8117A-Sensor_Out |
Sensor Out - OOPS sensor - out of paper sensor - detects the presence of the paper in the printer tray |
| C8117A-Sensor_Spot |
Sensor Spot - Spot sensor assembly is attached to the carriage assembly. |
| C8116-67057 |
Separator - Separation trough |
| C8117A-Separator |
Separator - Pad separator - assembled from plastic and rubber components; to help in separating sheet of media during printing from bottom trays. |
| C8117A-Guide |
Service Guide - Printer Reference Guide (not a service manual) - Contains information such as product information, operation overview, paper behavior, maintenance, ink safety, and removal / replacement of parts. This is not a service manual for technical repair. |
| C6030A |
Service Parts - HP Heavyweight Coated 914mm x 30,5m roll |
| C8116-67006 |
Service Parts - Cover - Front Left Svc |
| C8116-67009 |
Service Parts - Assy - Manual Trough Svc |
| C8116-67017 |
Service Parts - Stopper - Latch Svc |
| C8116-67018 |
Service Parts - Label - Warranty Void Svc |
| C8116-67021 |
Service Parts - Assy - Mss Tray 2 Svc |
| C8116-67022 |
Service Parts - Spring-X Bias, Duplexer Svc |
| C8116-67025 |
Service Parts - Solenoid-Overdrive Svc |
| C8116-67026 |
Service Parts - Pca-Analog, A-Size Svc |
| C8116-67035 |
Service Parts - Assy - Cable, Maxwell Left Svc |
| C8116-67036 |
Service Parts - Assy - Cable, Maxwell Right Sv |
| C8116-67038 |
Service Parts - Harness - Power On Svc |
| C8116-67039 |
Service Parts - Assy-Felt Oiler, 4-Pen Svc |
| C8116-67040 |
Service Parts - Tray - Reservoir Svc |
| C8116-67041 |
Service Parts - Cover-Connector, 4-Pen Svc |
| C8116-67045 |
Service Parts - Envelope Adjust Svc |
| C8116-67058 |
Service Parts - Tray 2/3 - Rp Guide Svc |
| C8116-67059 |
Service Parts - Assy - Edge Sensor Svc |
| C8116-67060 |
Service Parts - Strap-Blower Mounting Svc |
| C8116-67061 |
Service Parts - Shield-Emi, Flex Cable Svc |
| C8116-67063 |
Service Parts - Assy - Duplexer Svc |
| C8116-67065 |
Service Parts - Ferrite Core Cp Svc |
| C8116-67066 |
Service Parts - Spring-Encoder Svc |
| C8116-67067 |
Service Parts - Encoder Strip, A-Size Svc |
| C8116-67068 |
Service Parts - Support - Front Left Svc |
| C8116-67070 |
Service Parts - Assy - Elevator Drive Svc |
| C8116-67072 |
Service Parts - Mp Tray 1 Svc |
| C8116-69001 |
Service Parts - Bulkpack - Maxwell Base Svc |
| C8116-69032 |
Service Parts - Pca - Compton Svc |
| C8116-69044 |
Service Parts - Pca-Main, Office A Svc |
| C8116-69069 |
Service Parts - Titanium Svc |
| C8125-67013 |
Service Parts - Bij2300 250-Sht Bin/Feeder Svc |
| C8125-67015 |
Service Parts - Bij2300 500-Sheet Tray 2 Svc |
| C8116-67047 |
Service Station - Hewlett Packard Business Inkjet Service station |
| C8117A-Service_Station |
Service Station - Service station assembly - for conditioning the printheads when the carriage is in its home position |
| C8117A-SLED_Assy |
SLED Assembly - Sled assembly - white plastic piece with spring, wipers and boot (assembly that the ink cartridge parks on) - mounts on top of the service station assembly |
| C8117A-Slider |
Slider - Carriage base slider - plastic piece on the front end of the carriage that allows the carriage to slide side to side. |
| C8117A-Speaker |
Speaker - Speaker assembly - includes speaker cable. |
| C8117A-Spitton |
Spitton - Spittoon base - the bottom and main housing of the service station assembly - holds any residual ink from the print cartridge cleaning process |
| C8117A-Spring_Cmprsn |
Spring Compression - Compression spring - on pulley wedge, for carriage belt tension |
| C8116-67046 |
Tensioner - Belt tensioner assembly |
| C8117A-Trailing_Cbl |
Trailing Cable - Trailing cable for scanner - cable connects from scanner to pc board. |
| C8116-67010 |
Tray - Output tray assembly - Tray 1 |
| C8116-67011 |
Tray - Fixed input tray assembly - Tray 2 ( tray 3 700-sheet input unit is C8116-67069) |
| C8116-67069 |
Tray - 700-sheet input paper tray - Tray 3 - Extends media capacity |
| C8116-67071 |
Tray - 700-sheet input paper tray - Tray 3 - Extends media capacity |
| C8226A |
Tray - Business InkJet 3000 series 700-sheet paper tray |
| C8227A |
Tray - Business InkJet 3000 series 100-sheet multi-purpose tray |
| C8117A-Tray_Assy |
Tray Assembly - Paper input tray assembly for loading paper (bottom). |
| C8117A-Tray_Assy_CVR |
Tray Assembly Cover - Tray cover - the top cover for the paper pick up tray unit. |
| C8117A-Tray_Base |
Tray Base - Tray base- bottom base of the paper input tray. |
| C8117A-Window |
Window - Top/front access door assembly - print cartridge access door window. |
View service parts
