Your Scanner C7045-69001 is #3

HP parts picture diagram for R37-5020-000CN, RG0-1069-000CN, RG0-1014-000CN, RG0-1070-000CN, C7045-69001
Picture Items







Ref#
       Description (click to view price and order)


2
    Paper tray cover assembly - Includes clear plastic cover with width adjustment guides (Blue) for priority paper input - Part: RG0-1014-000CN


3
    HP Laserjet 1200 copy scan assembly. - Part: R37-5020-000CN


3
    HP Laserjet 1200 copy scan assembly. - Part: C7045-69001


4
    Pickup tray assembly - Paper input tray for the optional copier/scanner assembly - Part: RG0-1069-000CN


5
    Face-down tray assembly - Paper output tray for the optional copier/scanner assembly - Part: RG0-1070-000CN
