Your Power_Supply RH3-2252-000CN is #3

HP parts picture diagram for C9145-67901, RH3-2252-000CN, RG5-6964-000CN
Picture Items

       Description (click to view price and order)

    Formatter board assembly - Includes the formatter board and all the metal cage covers - Part: C9145-67901

    Low voltage power supply - For 110V to 127V AC operation - Includes the AC power input connector and power switch - Part: RH3-2252-000CN

    Carousel position and toner level photoelectric sensor PC board - L Shaped PC board with the two sensors - Part: RG5-6964-000CN
