Xerox parts list for 8825-Printer 8825

101K26083 Assembly - Control Console Assembly (8830) (W/TAG 32)

101K40051 Assembly - Control Console Assembly (8825) (W/TAG 32)

125K02220 Assembly - Scorotron Assembly

017E04250 Baffle - Baffle Stop

050E12851 Baffle - Developer Baffle

600K89510 Baffle - Mylar baffle Extension Kit (W/TAG 31)

028E11470 Bearing - Bearing Retainer

413W31054 Bearing - Bearing

023E01620 Belt - Auger Drive Belt

423W57550 Belt - Drive Belt

423W59001 Belt - Belt

423W72201 Belt - Sheet Drive Belt

035K05790 Blade - Photoreceptor Seal (Part of Cleaning Blade Kit) (REF: PL 9.5A Item 3) (REP 9.17)

600K59060 Blade - Cleaning Blade Kit (REP 9.4)

600K58730 Block - Left End Block Kit

093E01501 Bottle - Moisture Collection Bottle

093K02420 Bottle - Toner Bottle

030K57181 Bracket - LH Service Bracket

030K57191 Bracket - RH Service Bracket

068E17221 Bracket - Bracket

005E11130 Brake - Brake

017E07221 Brake - Clutch Brake

019E14350 Brake - Drag Brake (8830), Drag Brake (8825) (W/TAG 90)

115E01410 Brush - Static Brush

016E06020 Bushing - Bushing (8830), Bushing (8825) (W/TAG 90)

016E08931 Bushing - Bushing

420W10201 Cable - Cable Tie

008E06000 Cam - Cam Bracket

005K04131 Cap - RH End Cap

017K01120 Caster - Caster

030K57890 Catch - RH Catch Tray Bracket

030K57900 Catch - LH Catch Tray Bracket

073E11800 Catch - Catch Tray Kit

023E06750 Chain - Chain (8830)

023E17510 Chain - Chain (8825)

019E16080 Clamp - Left Corotron Clamp

019E19971 Clamp - Right Corotron Clamp

120E02160 Clamp - Twist Clamp

120E06510 Clamp - Twist Tie Clamp

019E07100 Clip - Cable Clip

019E15551 Clip - Bias Clip

019E21480 Clip - Clip

027E03950 Clip - Clip

120E04750 Clip - Cable Clip

120E05440 Clip - Clip

121E07510 Clutch - Clutch (Feed, Rewind) (REP 7.5 REP 7.6)

121K10612 Clutch - Clutch (REP 8.4)

162K29730 Controller - Controller Connector (See Note 1)

111K00021 Counter - Media Counter

048K44401 Cover - Right Side, Right Cover

048K45054 Cover - Top Cover (W/TAG 32)

048K47681 Cover - Right Side, Left Lower Cover

048K47692 Cover - Right Side, Right Lower Cover

048K47710 Cover - Right Side, Left Cover

048K79480 Cover - Left Middle Cover, Left Lower Cover

003E16521 Cutter - Cutter Latch

010K01360 Cutter - Media Cutter Slide

011E04470 Cutter - Cutter Interlock Actuator Lever

020E18830 Cutter - Cutter Drive Pulley

037K01100 Cutter - Media Cutter Assembly

127K26580 Cutter - Cutter Motor

130E03250 Cutter - Motion Sensor (REP 7.7)

004E00502 Damper - Foam Damper

604K00440 Damper - Foam Damper Kit (3/Kit)

600K08481 Deflector - Media Deflector Kit (7/Kit)

007K05260 Developer - Developer Drive Gear (43T/25T)

014K04730 Developer - Developer Support

014K04740 Developer - Developer Support (Drive Side)

030K56150 Developer - Developer Support

030K56160 Developer - Developer Support (Drive Side)

048E51410 Developer - Rear Developer Cover (W/TAG 6)

121K10422 Developer - Developer Module Assembly (REP 9.5)

127E10341 Developer - Drum/Developer Drive Motor

048K14304 Door - Front Door Cover Assembly (W/ TAG 32)

048K47700 Door - Rear Door

003E39000 Drawer - Drawer Handle (W/O TAG 32)

003E39001 Drawer - Drawer Handle (W/TAG 32)

009E27330 Drawer - Drawer Latch Spring

048K44880 Drawer - Drawer Cover

050K19612 Drawer - Roll Supply Drawer Assembly (REP 7.1)

050K53080 Drawer - Roll Supply Drawer Assembly (Sealed) (REP 7.1)

130E02271 Drawer - Drawer Interlock Switch

891E01960 Drawer - Drawer Label

891E01961 Drawer - Drawer Label (Optional Drawer)

007K05760 Drive Assembly - Rewind Drive Assembly

127K17882 Drive Assembly - Photoreceptor Drive Assembly

160K33322 Drive Assembly - Assembly (W/TAG 25) Driver PWB (A2) (W/O TAG 25)

054K12300 Duct - Fan Duct

152K36231 Duct - Jumper Harness (14 Conductor)

005E06810 Encoder Disk - Encoder Disk (REP 7.11)

127E11240 Fan - Fan

053E04750 Filter - Ozone Filter

142K01540 Filter - Filter

068E38113 Finger - Stripper Finger Bracket

110E05500 Finger - Stripper Finger Jam Switch (S1)

600K35880 Finger - Stripper Finger Spare Kit

600K68100 Finger - Special Stripper Finger Kit (FX Series Media Only)

005K02613 Fuse - LH Fuser Bearing

005K03430 Fuse - Fuser Hub

006E23471 Fuse - Fuser Drive Shaft

007E42780 Fuse - Fuser Gear (80t)

022K40050 Fuse - Fuser Heat Roll (REP 10.2)

126E00492 Fuse - Fuser Heat Rod (60 Hz) (REP 10.1)

126E00821 Fuse - Fuser Heat Rod (50 Hz) (REP 10.1)

127E10331 Fuse - Fuser Drive Motor

130K54841 Fuse - Thermal Fuse

600K45270 Fuse - Fuser Drive Shaft Kit

604K04430 Fuse - Fuser Control Kit (PIC) (W/TAG 50)

707W01652 Fuse - Fuser Triac (Q1) (REP 10.3)

035E37240 Gasket - Gasket

035E41150 Gasket - Gasket

035E41160 Gasket - Gasket

035K05900 Gasket - Gasket

007E01340 Gear - Toner Auger Drive Gear

007E14600 Gear - Rewind Gear (32T) (REP 7.2)

007E14610 Gear - Rewind Drive Gear (12T)

007E14650 Gear - Rewind Internal Gear (20T) (REP 7.2)

007E14690 Gear - Auger Drive Gear (37T)

007E14700 Gear - Auger Drive Gear (37T)

007E15351 Gear - Drive Gear/Coupling

007E16330 Gear - Cartridge Gear (44T)

007E16341 Gear - Cartridge Drive Gear (26T)

007E42570 Gear - Exit Drive Gear

007E42580 Gear - Take Up Gear

016E08080 Grommet - Grommet

019E33441 Ground - Ground Retainer

030E16161 Ground - Ground Clip

023K00942 Guide - Fabric Guide (REP 8.9)

038K06601 Guide - Media Exit Guide

038K09190 Guide Paper - Paper Guide

038K11070 Guide Paper - Paper Guide

003E39010 Handle - Handle

003K07581 Handle - Handle

117K26191 Harness - Detack Corotron Harness

117K26200 Harness - Transfer Corotron Harness

162K23421 Harness - Control Console To Controller Harness

162K23453 Harness - Motor Control Harness

162K28840 Harness - VPI Harness (8830) (W/TAG 90)

162K32650 Harness - Folder Enablement Harness

162K41440 Harness - Power Driver Harness (8830) (W/ TAG 90)

162K41460 Harness - A/B Switch to IOT Harness (8830) (W/TAG 90)

162K68390 Harness - Interconnect Harness

126K07330 Heater - Heater

101E12281 Housing - Display Housing

005K01351 Hub - Cartridge Hub

005K04201 Hub - LH Hub

007K08930 Idler - Idler Gear (40t/18T)

022E11441 Idler - Idler Roller

600K59260 Idler - Exit Idler Roll Kit

110E02640 Interlock - Front Door Cover Interlock Switch

110K08970 Interlock - Interlock Switch

600K60900 Kit - Diagnostic Kit

600K75321 Kit - Main PWB Kit (A3) (W/TAG 27)

600K81873 Kit - Circuit Assembly Kit (NACO) (W/ TAG 4, TAG 16, TAG 17, TAG 26, TAG 53, TAG 87)

600K81881 Kit - Circuit Assembly Kit (EO) (W/TAG 4, TAG 16, TAG 17, TAG 26, (W/O TAG 53)

600K81882 Kit - Circuit Assembly Kit (EO) (W/TAG 4, TAG 16, TAG 17, TAG 26, TAG 53,)

600K88890 Kit - Control Eprom Kit

003E19330 Knob - Cartridge Knob

092E22541 Labels - Label (Push Here)

092E22560 Labels - Label (Pinch Arrows)

092E36431 Labels - Label (Media Lead)

092E36450 Labels - Charge Corotron Label (Red Arrow)

096E72590 Labels - Label

096E72591 Labels - Label

096E78251 Labels - Control Console Label (8830) (W/ O TAG 32)

096E78252 Labels - Control Console Label (8830) (W/ TAG 32)

891E25140 Labels - Label (60HZ Only)

891E70530 Labels - Control Console Label (8825) (W/ O TAG 32)

891E70531 Labels - Control Console Label (8825) (W/ TAG 32)

049E06460 Lamp - RH Lamp Bracket

003E13020 Latch - Front Door Latch

003E18781 Latch - Latch

029E13701 Latch - Latch Pin

030K55634 Latch - Transport Latching Cover Assembly (8830) (W/TAG 32), Transport Latching Cover Assembly (8825) (W/TAG 90)

030K64020 Latch - Transport Latching Cover Assembly (8825) (W/O TAG 90)

101K25780 LED - Discharge LED

003E17610 Lock - Roll Lock

007E14710 Magnet - Magnetic Roll Drive Gear (40T)

121E01402 Magnet - Magnet

121E07680 Magnet - Magnet

121E10610 Magnet - Magnet

022K49205 Media - Media Transport Assembly (8830) (W/TAG 15), Media Transport Assembly (8825) (W/TAG 89) (REP 8.1,ADJ 8.1)

022K63750 Media - Media Transport Assembly (8825) (W/O TAG 89) (REP 8.1,ADJ 8.1)

126K05992 Module - Xerographic Module Assembly (60 Hz) (REP 9.1)

126K07152 Module - Xerographic Module Assembly (50 Hz) (REP 9.1)

600K58761 Module - Image Module Assembly Kit (W/ TAG 28)

600K60610 Module - AC Module Kit (TAG 5)

007K07561 Motor - Roll Drive Motor Assembly

127K04293 Motor - Roll Drive Motor (REP 7.9)

127K22600 Motor - Cartridge Drive Motor (MOT4) (REP 9.6)

160K23870 Motor - Drive Motor PWB

230W00652 Nut - Wing Nut

007K08920 Oil - Oiler Drive Gear

022K49131 Oil - Web Oiler (REP 10.9)

094K03301 Oil - Web Oiler Assembly (REP 10.7)

127K21990 Oil - Web Oiler Motor

108E01762 Pan - Ground Fault Panel

108E05310 Pan - Ground Fault Panel (20A) (W/O TAG 29)

537K51161 Pan - AO Spanish Language Eprom

160K30980 PC Board - Circuit Board (W/O TAG 28)

160K59660 PC Board - Pwb

160K63410 PC Board - Circuit Board (W/TAG 28)

600K75311 PC Board - Driver PWB (A2) (W/TAG 25)

006E23540 Pin - Sheet Pinch Shaft (8830), Sheet Pinch Shaft (8825) (W/TAG 90)

006E42300 Pin - Pinch Roll Shaft

022E09390 Pin - Sheet Pinch Roll (8830) (REP 8.6), Sheet Pinch Roll (8825) (W/TAG 90) (REP 8.6)

022E10060 Pin - Roll Feed Pinch Roll (REP 7.3)

022K49380 Pin - Pinch Roll

029E14750 Pin - RH Support Pin

029E14760 Pin - LH Support Pin

029E23670 Pin - Pin

029K01111 Pin - Pin

600K58750 Pin - Pin Array Kit (REP 9.8)

033K02040 Plate - Pressure Plate B (REP 8.5)

033K02430 Plate - Pressure Plate A (REP 8.5)

048E39380 Plate - Kickplate

891E09080 Plate - Logo Plate

021E07660 Plug - Cap Plug

117K22761 Power Cord - Power Cord (60HZ)

117K27550 Power Cord - Power Cord (50 Hz)

117K32660 Power Cord - Item 1) Power Cord (25V PS)

105E13850 Power Supply - Power Supply (5V)

105E13863 Power Supply - Power Supply (25V)

105K13542 Power Supply - High Voltage Power Supply (REP 3.2)

105K15863 Power Supply - DC Low Voltage Power Supply

105K18273 Power Supply - DC Low Voltage Power Supply

007E05221 Pulley - Auger Gear Pulley

007E44391 Pulley - Drive Pulley (28T)

020E04350 Pulley - Auger Pulley

020E13603 Pulley - Drive Motor Pulley

020E13853 Pulley - Sheet Drive Pulley

020E20680 Pulley - Drive Pulley (34T)

020E26340 Pulley - Gear Pulley

020E26350 Pulley - Exit Drive Pulley

020K08080 Pulley - Clutch Pulley

062E05461 Reflector - Reflector

006K17441 Registration - Registration Drive Roll (REP 8.17)

020E12353 Registration - Registration Drive Pulley

022E10531 Registration - Registration Pinch Roll (REP 8.12)

030K37830 Registration - Registration Sensor Bracket

130E05990 Registration - Media Registration Sensor (Q1) (REP 8.8)

423W64001 Registration - Registration Drive Belt (REP 8.13)

109E01040 Relay - AC Relay (K1) (50/60 Hz), AC Relay (K3) (60 Hz) (K1/K3)

600K37740 Repair Kit - Corotron Repair Kit

604K00080 Repair Kit - Seal Repair Kit (W/TAG 51)

103E02721 Resistor - Ballast Resistor (R1/R2) (60HZ)

103E02731 Resistor - Ballast Resistor (R1/R2) (50HZ)

003K09130 Retainer - Fabric Guide Retainer Handle

028E07771 Retainer - Retainer

029E14460 Retainer - Retainer

009E27340 Ring - Roll Lock Spring

009E27351 Ring - Pinch Roll Spring

009E30860 Ring - LH Spring

009E30870 Ring - RH Spring

009E32480 Ring - Registration Support Spring

009E32490 Ring - Sheet Pinch Spring (8830), Sheet Pinch Spring (8825) (W/TAG 90)

009E32500 Ring - Pinch Roll Spring

009E32510 Ring - Compression Spring

009E32790 Ring - Lock Spring

009E38060 Ring - Spring

009E41251 Ring - Coupling Spring

009E43260 Ring - Motor Spring

009E46870 Ring - Drain Tube Spring

009E61600 Ring - Spring

009E75260 Ring - Spring

013E00803 Ring - Auger Bearing

013K00380 Ring - Bearing

028E07430 Ring - Retaining Ring

115E02231 Ring - Ground Ring

413W30854 Ring - Bearing

809E02290 Ring - Shaft Spring

160K73561 Rod - Heat Rod Control PWB Assembly (50 Hz) (W/TAG 50)

006K15670 Roller - Exit Roll (REP 8.16)

022K28930 Roller - Roll Feed Drive Roll (REP 7.4)

600K58720 Roller - DRS Roller Kit

600K58740 Roller - Roller Kit

604K00520 Roller - Roller Kit (2/Kit) (W/TAG 52)

062E08051 Screen - Screen

003E44550 Screw - Screw (M4)

026E11970 Screw - Shoulder Screw

026E57690 Screw - Screw (M4 X 30)

035E12210 Seal - Seal

035E41210 Seal - Seal

035K04581 Seal - Seal

035K05950 Seal - Toner Exit Seal

049E54980 Sensors - Sensor Bracket

130K30381 Sensors - Toner Cartridge Home Sensor (REP 9.12,ADJ 9.5)

130K51801 Sensors - Position Sensor

130K55130 Sensors - Web Motion Sensor

001R00535 Service Parts - Photoreceptor (REP 9.3)

003E13010 Service Parts - Keeper

005K04151 Service Parts - Coupling

010E04190 Service Parts - Trickle Slide

010K01351 Service Parts - Slide

029E24860 Service Parts - Fastener

029E28060 Service Parts - Fastener

108E02282 Service Parts - Residual Current Breaker (20A) (W/ TAG 29)

120E02150 Service Parts - Twist Clamp

125K02580 Service Parts - Transfer/Detack Corotron (REP9.9)

130K53300 Service Parts - Xerox Part

537K51151 Service Parts - AO Portuguese Language Eprom

006K15640 Shaft - Shaft Assembly

029E12930 Shaft - Rewind Shaft

006K15682 Sheet - Sheet Drive Roll (8830) (REP 8.7), Sheet Drive Roll (8825) (W/TAG 90) (REP 8.7)

002E40470 Shield - Top Shield Door

038E06610 Shield - Rear Detack Corotron Shield

038E06620 Shield - Front Detack Corotron Shield

055E38100 Shield - Shielding Pad

055K13830 Shield - Sump Shield (REP 9.13)

055K13840 Shield - Top Shield

014E20541 Spacer - Left Hinge Spacer

014E20551 Spacer - Right Hinge Spacer

007E16410 Sprocket - Main Drive Sprocket (10T)

007E19071 Sprocket - Sprocket (50T)

001E23080 Strip - Toner Strip

030K55720 Strip - Stripper Bracket Assembly

022E11540 Support - Support Roller

032E10830 Support - Stacker Support

073E11710 Support - Tray Support Kit

110K03731 Switch - Sheet Feed Switch (8830), Sheet Feed Switch (8825) (W/TAG 90)

110K08711 Switch - Buckle Switch (Upper) (REP 8.4), Buckle Switch (Lower) (REP 8.2)

110K09430 Switch - Switch

160K37310 Switch - A/B Switch PWB (8830) (W/TAG 90)

130K54730 Thermistor - Thermistor

052E07900 Tube - Moisture Drain Tube

052E07910 Tube - Moisture Collection Tube

052K03580 Tube - Roll Support Tube Assembly

054E03181 Tube - Pressure Equilizer Tube (REP 9.8)

054E03491 Tube - Pressure Equilizer Tube (REP 9.18)

035K05941 Waste - Waste Bracket Seal

054E06533 Waste - Toner Waste Tube

094K00085 Waste - Waste Toner Auger

146K00461 Wheel - Encoder Wheel

Xerox 8825 (8825-Printer)

Xerox parts list for 8825-Printer Xerox 8825 Printer
