Xerox parts list for DocuWide-6030 DocuWide 6030

022K62913 Assembly - BTR/DTS Assembly

022K62922 Assembly - DTS Assembly

059K23120 Assembly - B-Tra. Assembly (Left)

059K23130 Assembly - B-Tra. Assembly (Right)

130K61660 Assembly - Lph Assembly

604K19170 Assembly - BCR Assembly

055K26082 Baffle - Regi. Baffle

055K26482 Baffle - Swing Baffle

055K26510 Baffle - A-Tra. Upper Baffle Assembly (REF: PL2.2)

055K26521 Baffle - Baffle Assembly (Center)

055K28140 Baffle - Exit Upper Baffle Assembly

604K19230 Baffle - Baffle Assembly

604K19270 Bearing - Bearing and Gear Kit

423W52154 Belt - Belt (REP 9.11)

033K93831 Blade - Cleaning Blade (REP 9.8)

033K94010 Blade - Developer Blade Assembly

014E47501 Block - Catch Tray Block

093K98131 Bottle - Toner Bottle

068K42740 Bracket - Right Support Bracket

068K42750 Bracket - Left Support Bracket

830E84771 Bracket - Bracket

115E01410 Brush - Static Brush

117K35150 Cable - Cable (Primary IDE)

117K35160 Cable - Cable (Secondary IDE)

117K35171 Cable - VPI Cable

117K35211 Cable - Cable

006K21670 Cartridge - Toner Auger

052K91890 Cartridge - Toner Pipe Assembly

802K64070 Cartridge - Toner Cartridge Cover

050K59220 Catch - Catch Tray

121E86350 Catch - Catch Magnet

101K46300 Chassis - Breaker Chassis Assembly

054K21710 chute - Exit Lower Chute (GCO)

054K23020 chute - Inlet Chute Assembly

802K27160 Cleaner - Cleaner Housing Assembly

019E51420 Clip - Canoe Clip

121K12140 Clutch - Clutch

121K12620 Clutch - MSI Take Away/Feed Clutch

121K26260 Clutch - A-Tra. Clutch

127K32930 Controller - Controller Fan

802E29031 Cover - Rear Lower Cover

802E35630 Cover - Inner Cover

802E35650 Cover - Rear Top Cover

802E35660 Cover - MSI Left Cover

802E35681 Cover - Front Upper Cover

802K28121 Cover - Top Cover

802K30481 Cover - Front Top Cover

802K30563 Cover - RFC Cover (P/O Item 1)

802K30591 Cover - Cover

802K36440 Cover - Top Cover Assembly

802K37321 Cover - Exit Cover

802K43030 Cover - Front Kick Cover

802K51050 Cover - Right Rear Cover

802K51081 Cover - Left Lower Cover

802K51980 Cover - MSI Upper Cover

802K65770 Cover - Rear Upper Cover

802K65780 Cover - Left Upper Cover

802K65790 Cover - Right Lower Cover

802K65800 Cover - Right Upper Cover

037K90812 Cutter - Cutter Assembly

033K93970 Developer - Developer Blade

604K19260 Developer - Developer Gear and Tracking Roll

802K64230 Developer - Developer Assembly

121K28871 Disk - Hard Disk (pre-install w/patch seal and inch screw)

802K30586 Door - RFC Door (P/O Item 1)

001R00574 Drum - Drum

127E82880 Drum - Drum Motor

160K76380 Drum - Drum Motor PWB

604K19240 Drum - Drum Kit (without Drum)

146K90760 Encoder - RFC 1,2 Paper Length Encoder

127K35630 Fan - Heatsink Fan

059K19860 Feed Rollers - Feed Roller

006K21661 Finger - Drum Finger Shaft (Roll and Cut Paper)

019E22120 Finger - Stripper Finger

019K98110 Finger - Drum Finger Assembly

126K17551 Fuse - Fuser Assembly (REF: PL5.2) (NASG)

127K29330 Fuse - Fuser Exhaust Fan 1

127K32782 Fuse - Fuser Drive Motor

007E71540 Gear - Gear Auger

604K19310 Gear - Gear/Belt Kit

604K19350 Gear - Roll and Gear Kit

604K19360 Gear - Gear Kit

003K85930 Handle - Handle Assembly

162K64822 Harness - Wire Harness (4 Roll)

962K06042 Harness - Wire Harness (4 Roll)

962K07821 Harness - Wire Harness

126K15020 Heater - Center Heater Rod

126K15030 Heater - Side Heater Rod

126K15240 Heater - Sub Heater Rod

126K16030 Heater - RFC Heater

022E24600 Idler - Idler Roll

110E95990 Interlock - Interlock Bypass Switch

110E97990 Interlock - Front Interlock Switch

893E16190 Labels - Size Label

893E16200 Labels - (6030/6050) Roll Upper Label

015K50440 Latch - Latch Plate (Right)

068E48710 Latch - Latch

110E98710 Latch - RFC 1,2 Latch Switch

604K19250 Latch - Latch Kit

604K19290 Latch - Latch Kit

604K19330 Latch - Latch Kit

604K19340 Latch - IIT Safety Latch Kit

060K93953 Lever - Toner Box/Lever Assembly

121K33770 Magnet - Magnet Roll

007K86871 Motor - RFC 1 Take Away Motor

007K87183 Motor - Roll 1 Feeder Motor

007K87194 Motor - Roll 2 Feeder Motor

007K87204 Motor - Roll 4 Feeder Motor

127K32791 Motor - Main Motor Assembly

127K33380 Motor - MSI Lift Motor

160K77942 Motor - RFC 1 Motor PWB

802K51200 Pan - Control Panel Assembly

048K70043 PC Board - Console PWB

160K61640 PC Board - Ciol PWB

160K75654 PC Board - Iot Cpu Pwb

160K76334 PC Board - Lph Control Pwb

160K76451 PC Board - Iit If Pwb (Ec5, Ec3)

160K76750 PC Board - C/P Control PWB

160K77190 PC Board - SUB Console PWB

160K84831 PC Board - VPI Centro PWB

160K86800 PC Board - MEM-PWB (256meg)

160K86820 PC Board - MEM-PWB (512meg)

160K88462 PC Board - Iot If Pwb

604K19200 Pin - (P/O Item 11) Pinch Roller Assembly

604K19300 Pin - Pinch Roll Assembly

068K21501 Pinch Assembly - Support Pinch Assembly

015E75310 Plate - Bias Plate

056K02740 Plate - Logo Plate

105E09761 Power Supply - Lvps 24v-B

105E09831 Power Supply - 5v Lvps (220v) (Rep 1.4)

105E11351 Power Supply - Lvps 24v-A

105K19323 Power Supply - Hvps 1

105K19341 Power Supply - Hvps2

105K20211 Power Supply - Lvps Ess

001K76780 Rail - Left Rail

001K76791 Rail - Right Rail

604K19180 Reference - Gear Assembly (Reference number P/O 5, 6)

101K35290 Relay - Relay Chassis Assembly (GCO)

109E92360 Relay - Relay (24V)

109E92420 Relay - Main Relay

009E61260 Ring - Spring

604K19190 Ring - Spring Assembly

809E30031 Ring - Gas Spring (6030/6050 MF)

809E33510 Ring - Nip Spring

809E34010 Ring - Spring

809E37930 Ring - Gas Spring (6030/6050 EP)

809E38131 Ring - Gas Spring (6030/6050 EP +MSI)

809E38141 Ring - Gas Spring (6030/6050 MF +MSI)

809E63000 Ring - Spring Idler

059K19830 Roller - Heat Roll

059K19870 Roller - Take Away Roller

059K19880 Roller - Vertical Roller

059K21080 Roller - Take Away Roll

059K21410 Roller - Retard Roll Assembly

059K24500 Roller - Pressure Roller

604K19210 Roller - A-Tran Roller Assembly

604K19220 Roller - Reg Roller Assembly

604K19280 Roller - Exit Roller Asembly

026E66671 Screw - Screw

026K01280 Screw - Screw

035K82180 Seal - Toner Seal

035K82580 Seal - Seal

107E06650 Sensors - Roll 1, 3 No Paper Sensor

107E08680 Sensors - Platen Angle Sensor

130E82650 Sensors - Tray 4 Feed Out Sensor

130E83760 Sensors - MSI Length Sensor

130E96200 Sensors - Roll 2, 4 Jam Sensor

130K61690 Sensors - Sensor Assemlby

130K62061 Sensors - Humidity Sensor

130K63191 Sensors - Toner Sensor Assembly

130K84531 Sensors - Toner Empty Sensor

022K62523 Service Parts - BTR (P/O Item 23)

121K28420 Service Parts - Fdd

137E07890 Service Parts - Ic-Cpu

006K29840 Shaft - Exit Shaft

830E96350 Shaft - Exit Shaft Support

068K21752 Shelf - Lower Shelf

068K24280 Shelf - Upper Shelf

121K27060 Solenoid - MSI Nudger Solenoid

121K30590 Solenoid - Drum Finger Solenoid

160K76710 Stamp - Stamp PWB

031E94131 Stopper - Stopper

110E10650 Switch - IOT Mode Switch

110E98790 Switch - Paper Heater Switch

130K86451 Thermistor - Thermistor (RT10-1, RT10-2, RT10-3, RT10-4)

130K87550 Thermistor - Exit Temp Thermistor

130E82881 Thermostat - Over Heat Thermostat (THS10-1)

050K59120 Tray - Scanner Tray

160K75672 Tray - I/O EXP RFC 2, Tray 3 PWB

052K07222 Tube - Tube

127K32370 Vacuum - B-Tra. Vacuum Fan 1

121K24421 Wing - Swing Clutch Assembly
