| C9017-80033 |
Absorber - Absorber - Absorbs excess color ink during the cleaning process |
| C9017-80034 |
Absorber - Absorber - Absorbs excess black ink during the cleaning process |
| Q8401A-Absorber |
Absorber - Ink service station (ISS) bottom absorber foam - absorbs ink during the cleaning process. Service station absorber (sponge) - soaks up used ink during cartridge cleaning. Works as sled filters. |
| Q8401A-AC_Adapter |
AC Adapter - Power supply module or adapter - one end for connecting to the printer and other end to the power cord, or your ac adapter may have the pwr cord attached. |
| Q8401A-Actuator |
Actuator - Actuating unit. this part usually causes the carriage assembly to stalls on the left side of the printer, verify that the clutch actuator arm (slider arm). |
| Q8401A-ADF_Arm |
ADF Arm - Senses paper in the ADF area tray / feeder tray. this is a front flapper arm - part of the paper separation mechanism for the paper pickup assembly - mounts just in front of the front separation belts in the ADF assembly. |
| Q8401A-ADF_Feed_Assy |
ADF Feed Assembly - ADF assembly - does not include ADF input tray. ADF assembly includes the complete ADF assembly (motor, gears, rollers, sensor, does not include the ADF pad or plastic flatbed cover. (for entire unit please see ADF unit assembly). |
| Q8401A-ADF_Input_Tray |
Adf Input Tray - ADF tray ( for automatic document feeder) this is where papers are placed for feeding into unit. |
| Q8401A-ADF_Motor |
ADF Motor - ADF motor - the scanner ADF motor is located on left rear corner of ADF drive, location varies from each unit. however, this is the main motor on the ADF unit. |
| Q8401A-ADF_Output_Tray |
ADF Out Put Tray - ADF out put tray is where paper come out of ADF (automatic document feeder). For this unit, we will ship the entire ADF Assembly. |
| Q8401A-ADF_Pad |
ADF Pad - ADF paper seperation pad assembly - mounts in the center of the ADF separation pad frame assembly. this pad prevents from multiple feeding or preventing paper jams while faxing, scanning, or copying. |
| Q8401A-ADF_PC_BRD |
ADF PC Board - Control Board on the ADF unit |
| Q8401A-ADF_Roller_Kit |
ADF Roller Kit - ADF upper pick roller replacement kit. these are the rollers that feed paper into the feeder to be scan, copy, or faxed. |
| Q8401A-ADF_Scanner |
ADF Scanner - ADF scanner (optical) assembly - includes the chassis assembly, scanner lens assembly (includes the charge coupled device (ccd)), the scanning lamp, ADF analog processor board, and ADF inverter board - this is the assembly that scans, copies documents. |
| Q8401A-ADF_Sensor_BRD |
ADF Sensor Board - ADF sensor pc board assembly - narrow strip pc board with the two document skew sensors, registration sensor, and timing sensor - mounts on top of the registration guide assembly in the ADF main assembly |
| Q8401A-ADF_Unit_Assy |
ADF Unit Assembly - Complete replacement assembly unit for Officejet Copier, top assembly only. This includes the ADF (automatic document feeder) for this unit. |
| Q8401A-Arm_Delivery |
Arm Delivery - Paper sensing arm - for 'paper out' or delivering paper sensing arm |
| Q8401A-Arm_Door |
Arm Door - Carriage access door sensor arm |
| Q8401A-Arm_Pickup |
Arm Pick Up - Paper detection arm - for registration plate on picking up paper |
| Q8401A-Arm_Plate |
Arm Plate - Lever arm - used to lift the pressure plate lifter |
| Q8401A-Arm_Sensing |
Arm Sensing - Arm assembly senses paper in bottom tray |
| Q8401A-Arm_Tension |
Arm Tension - Tension arm - maintains tension on carriage belt |
| Q8401A-Belt_ADF |
Belt ADF - Transport belt motor - provides the drive to transport paper through the ADF unit. this belt goes in the ADF assembly drive unit |
| Q8401A-Belt_Carriage |
Belt Carriage - Carriage belt - moves the carriage assembly across the carriage rod |
| Q8401A-Belt_Duplex |
Belt Duplex - Duplex timing belt - small belt that goes on the duplexer unit |
| Q8401A-Belt_Paper |
Belt Paper - Paper drive belt (usually a small belt) - this belt attaches to a gear which is driven by the paper drive motor assembly. |
| Q8401A-Belt_Scanner |
Belt Scanner - Scanner assembly belt. belt moves the scanner while copying or scanning documents. |
| Q8401A-Bezel |
Bezel - Front panel overlay (bezel) - (english) control panel bezel - frame around display and control panel |
| Q8401A-Bracket_Left |
Bracket Left - Left bracket - carriage rod adjustment bracket (left) |
| Q8401A-Bracket_Right |
Bracket Right - Right bracket - carriage rod adjustment bracket (right) |
| Q8401A-Bracket_Tension |
Bracket Tension - Belt tension bracket - holds the carriage belt idler pulley |
| 8121-0868 |
Cable - Universal Serial Bus (USB) interface cable (Black) - Type 'A' connector to type 'B' connector - 1.83m (6.0ft) long |
| Q8401A-Cable_Carriage |
Cable Carriage - Cable assembly which connects the main logic board to the carriage motor |
| Q8401A-Cable_Interface |
Cable Interface - Parallel cable - connects from your printer to computer via your parallel port. |
| Q8401A-Cable_Mchnsm |
Cable Mechanism - Cable assembly which connects the main logic board to the print mechanism |
| Q8401A-Cable_Panel |
Cable Panel - Cable Panel assembly - includes ribbon cable this is the cable that connects to the control panel or display. |
| Q8401A-Cable_USB |
Cable USB - This interface cable is the standard 2.0 usb cable that connects to your printer and computer for printing. |
| Q8401A-Cam |
Cam - Drawer cam - short, spring loaded lever attached to the paper tray frame - used to draw input tray into position |
| Q8401A-Cap_Lifter |
Cap Lifter - These lifter caps hold the pressure plate lifter and the kicker spring in place. |
| UG604E |
Care Pack - HP 2 year Care Pack w/Next Day Exchange for Printers |
| UG607E |
Care Pack - HP 3 year Care Pack w/Next Day Exchange for Printers |
| UH608E |
Care Pack - HP 4 year Care Pack w/Next Day Exchange for Printers |
| US284E |
Care Pack - HP Basic Installation Service for one consumer printer with wireless capability |
| US285E |
Care Pack - HP Premium Installation Service with wireless network setup for up to three PCs and/or printers |
| Q8401A-Carriage_Assy |
Carriage Assembly - Ink cartridge carriage assembly - includes carriage, felt, felt retainers, ink cartridge latches, trailing cable, pc board, belt attachment hardware, and slider. |
| Q8401A-Carriage_Base |
Carriage Base - Carriage base or pre-loader assembly - mounted to bottom of carriage base |
| Q8401A-Carriage_Belt |
Carriage Belt - Carriage drive belt, this belt is attached to the carriage and carriage motor, it moves the carriage side to side while priting. |
| Q8401A-Carriage_Cable |
Carriage Cable - Flex circuit cable which connects the head driver board to the carriage assembly. in some units it is also known as the trailing cable, this cable moves along with the carriage unit (side to side). |
| Q8401A-Carriage_Latch |
Carriage Latch - A-arm latch - retains latch over the printheads on the carriage |
| Q8401A-Carriage_Latch_CVR |
Carriage Latch Cover - The carriage latch is used to keep the cartridge(s) in place. this latch(s) hold the cartridge(s) in place while carriage is printing or idle. |
| Q8401A-Carriage_Motor |
Carriage Motor - Carriage motor moves the carriage unit side to side. the carriage belt goes arround this motor, which controls carriage movement. |
| Q8401A-Carriage_Only |
Carriage Only - Carriage only - includes carriage, felt, felt retainers, ink cartridge latches - does not include trailing cable, pc board, belt attachment hardware, or slider (for complete carriage unit, please see carriage assembly). |
| Q8401A-Carriage_PC_BRD |
Carriage PC Board - This pc board attaches on the carriage, it is usually a small pc board that has carrage cable attached to it. |
| 5069-7146 |
Cartridge - Ink cartridge return kit (TIJ 2.x) - Includes box and instructions |
| C9369EE |
Cartridge - HP 348 Tri-color Photo Inkjet Cartridge - 13ml, prints approximately 130 (4 x 6-inch) color photos (Europe) |
| C9369HE |
Cartridge - Cartridge for DeskJet 6620 Series, DeskJet D41XX Series, Officejet H470 Series, OfficeJet K7100 Series |
| CB335EE |
Cartridge - Cartridge for OfficeJet J6480, HP Officejet J6400 All-in-One, HP Officejet J6400 All-in-One Printer series, PhotoSmart C42X0 Series |
| CB335HE |
Cartridge - Cartridge for OfficeJet J6480, HP Officejet J6400 All-in-One, HP Officejet J6400 All-in-One Printer series, PhotoSmart C42X0 Series |
| CB335WN |
Cartridge - Cartridge for OfficeJet J6480, HP Officejet J6400 All-in-One Printer series, HP Officejet J6400 All-in-One, DeskJet D42XX Series |
| CB336EE |
Cartridge - Cartridge for HP Officejet J6400 All-in-One, PhotoSmart C42X0 Series, Photosmart C4283 All-in-One, HP Photosmart C4200 All-In-One printer series |
| CB336HE |
Cartridge - Cartridge for HP Officejet J6400 All-in-One, PhotoSmart C42X0 Series, Photosmart C4283 All-in-One, HP Photosmart C4200 All-In-One printer series |
| CB336WN |
Cartridge - Cartridge for OfficeJet J6480, HP Officejet J6400 All-in-One Printer series, HP Officejet J6400 All-in-One, DeskJet D42XX Series |
| CB337EE |
Cartridge - Cartridge for OfficeJet J6480, HP Officejet J6400 All-in-One, HP Officejet J6400 All-in-One Printer series, PhotoSmart C42X0 Series |
| CB337HE |
Cartridge - Cartridge for OfficeJet J6480, HP Officejet J6400 All-in-One, HP Officejet J6400 All-in-One Printer series, PhotoSmart C42X0 Series |
| CB337WN |
Cartridge - Cartridge for OfficeJet J6480, HP Officejet J6400 All-in-One Printer series, HP Officejet J6400 All-in-One, DeskJet D42XX Series |
| CB338HE |
Cartridge - Cartridge for HP Officejet J6400 All-in-One, PhotoSmart C42X0 Series, Photosmart C4283 All-in-One, HP Photosmart C4200 All-In-One printer series |
| CB338WN |
Cartridge - Cartridge for HP Photosmart C4200 All-In-One printer series, PhotoSmart C4210 Series, Photosmart C4273 All-in-One, Photosmart C4293 All-in-One |
| Q8401A-Chassis |
Chassis - Chassis assembly - the large plastic item that forms the base of the print mechanism |
| Q8401A-Clutch_ADF |
Clutch ADF - ADF paper clutch unit. clutch that controls movement on the ADF feeder |
| Q8401A-Clutch_Feed |
Clutch Feed - Clutch unit resposible for unit picking up paper from the pick up unit. |
| Q8401A-Control_Panel |
Control Panel - Control panel assembly - control buttons and display on top front of the unit. |
| Q8401A-Cover_Back |
Cover Back - Back cover of printer, it is usually removed to clear paper jams. |
| Q8401A-Cover_Cartridge |
Cover Cartridge - This is the cover/ door that is opened to remove the cartridge(s) - usually, when this door opens the carriage moves. |
| Q8401A-Cover_Main |
Cover Main - This is the main cover of the printer. it is the biggest piece of plastic the printer is made off. |
| Q8401A-Deflector |
Deflector - Paper deflector - guides paper out of dispose assembly - through the internal paper path cover. paper deflector - directs paper from the media chassis to the print section of the printer chassis assembly |
| Q8401A-Display |
Display - Status led display (LCD display assembly). |
| Q8401A-Door_Carriage |
Door Carriage - Main front access door - covers the top of the printer and provide access to the carriage when open. |
| Q8401A-Door_Cartridge |
Door Cartridge - Small front access door (drop down door) - for accessing print cartridge window - for print cartridge access door. |
| Q8401A-Door_Rear |
Door Rear - Rear cleanout door assembly - rear paper jam clean out door assembly. |
| Q8401A-Drive_Assy |
Drive Assembly - Paper drive roller kit - includes roller assembly, bushings, gear on roller, transmission gear kit, encoder disc, end thrust (axial) spring. |
| Q8401A-Drive_Assy_ADF |
Drive Assy ADF - Media chassis assembly (paper drive) - moves paper from ADF assembly to scanner assembly - includes media chassis, rollers, gears, flag, sensor, deflector, cable, springs |
| Q8401A-Duplexer |
Duplexer - Auto duplexer assembly - provides double sided printing capability |
| C9045-80011 |
Encoder - Encoder strip (clear strip with position marks) - Used by the sensor in the carriage assembly to determine position |
| Q8401A-Encoder |
Encoder - Encoder spring - provides tension for encoder strip |
| Q8401A-Encoder_Disk |
Encoder Disk - Disk encoder - helps to provide position information of the paper |
| Q8401A-Encoder_Strip |
Encoder Strip - Encoder strip - carriage position sensor reference |
| Q8401A-Extender_ADF |
Extender ADF - Paper extension for the automatic document feeder (ADF) input tray |
| Q8401A-Extender_Input |
Extender Input - Tray extension assembly (stopper) - tray with a paper stop on the input tray - extends to accomodate different media lenths |
| Q8401A-Extender_Output |
Extender Output - Paper exit tray extension |
| Q8401-60001 |
Faceplate - Front faceplate (bezel) assembly - Photosmart C4580 All-in-One printer series (English, for use in North America) |
| Q8401-60002 |
Faceplate - Front faceplate (bezel) assembly - Photosmart C4580 All-in-One printer series (English and Traditional Chinese, for use in Asia Pacific) |
| Q8401-60003 |
Faceplate - Front faceplate (bezel) assembly - Photosmart C4580 All-in-One printer series (Korean, for use in Asia Pacific) |
| Q8401-60004 |
Faceplate - Front faceplate (bezel) assembly - Photosmart C4580 All-in-One printer series (English, for use in Asia Pacific) |
| Q8401A-Fan_PC_BRD |
Fan PC Board - Fan to cool power supply unit |
| Q8401A-Fan_Vaccum |
Fan Vaccum - Vacuum fan assembly |
| Q8401A-Feed_Rollers |
Feed Rollers - Feed roller assembly - includes frame asembly, shaft with rollers, and encoder disk |
| Q8401A-Feed_Rollers_ADF |
Feed Rollers ADF - ADF feed roller kit - includes all rollers that feed paper through the feeder. |
| Q8401A-Flag_ADF |
Flag ADF - Photo-sensor assembly - includes the sensor and mounting bracket - paper pickup roller home position sensor - activated by the sensor flag on the pickup roller assembly - mounths on the front frame of the ADF paper pickup assembly |
| Q8401A-Flag_Paper |
Flag Paper - OOPS flag - out of paper sensor |
| Q8401A-Formatter |
Formatter - Formatter board assembly, this board communicates with your computer device and has MAC port connector. |
| Q8401A-Front_Panel |
Front Panel - Front panel assembly - includes lcd and actuator buttons |
| Q8401A-Gear_Assy |
Gear Assembly - ADF gear assembly driven by ADF main motor |
| Q8401A-Gear_Cluster |
Gear Cluster - Cluster gear, large gear on service station |
| Q8401A-Gear_Double |
Gear Double - Transfer gear - has double gear attached on service station |
| Q8401A-Gear_Main |
Gear Main - Paper pickup drive assembly - gear assembly located on right side of paper pickup assembly. gear moves the main paper pick up roller. |
| Q8401A-Gear_Station |
Gear Station - Gears on shaft of spittoon station |
| Q8401A-Glass_ADF_Window |
Glass ADF Window - Small glass piece used when scanning - copying - faxing with ADF feeder for this unit will ship Q5888-00002. |
| Q8383-00006 |
Glass Assembly - Glass Assembly for DESKJET F4480, Photosmart C4700 All-in-One printer series, HP Photosmart C4480 All-In-One Printer series, Photosmart C4450 |
| Q8401A-Glass_Assy |
Glass Assembly - Main top copier glass assembly. |
| Q8401A-Guide_Paper |
Guide Paper - Upper paper guide - spring loaded flat plate that presses the media against the top of the feed roller assembly - caution: this part can easily be broken |
| Q8401A-Hinge_Cvr |
Hinge - Single cover end M-Hinge, Hinge is for top cover supporting opening and closing of the cover. Most covers use 2 hinges, this price includes 1pc Hinge. |
| Q8401A-Holder |
Holder - Ink cartridge holder - located on carriage unit, holder secures ink cartridge in place. |
| Q8401A-Idler |
Idler - Scanner belt idler assembly - maintains scannter belt tension. |
| Q8401A-Ink_DLVRY |
Ink Delivery System - RIDS assembly - replaceable ink delivery system - transports ink from ink supply station to carriage assembly |
| Q8401A-Ink_Supply_Station |
Ink Supply Station - Ink supply service station (iss) assembly |
| Q8401A-Lid_Cover_Assy |
Lid Cover Assy - Top glass copier cover. Lid that pressed document onto the glass for copying or scanning document. |
| Q8400-90033 |
Manual - Basics guide - Photosmart C4500 All-in-One printer series (English) |
| Q8400-90035 |
Manual - Basics guide - Photosmart C4500 All-in-One printer series (English and French) |
| Q8400-90046 |
Manual - Basics guide - Photosmart C4500 All-in-One printer series (English and Traditional Chinese) |
| Q8400-90047 |
Manual - Basics guide - Photosmart C4500 All-in-One printer series (Thai) |
| Q8400-90048 |
Manual - Basics guide - Photosmart C4500 All-in-One printer series (English and Hindu) |
| Q8400-90049 |
Manual - Basics guide - Photosmart C4500 All-in-One printer series (Korean) |
| Q8400-90052 |
Manual - Setup guide - Photosmart C4500 All-in-One printer series (English, Spanish, and French) |
| Q8400-90061 |
Manual - Setup guide - Photosmart C4500 All-in-One printer series (English, Traditional Chinese, Korean, and Simple Chinese) |
| Q8400-90062 |
Manual - Setup guide - Photosmart C4500 All-in-One printer series (English, Thai, Hindu and Traditional Chinese) |
| Q8401A-Motor_ADF |
Motor ADF - ADF motor unit - drives ADF rollers on the feeder assembly |
| Q8401A-Motor_Carriage |
Motor Carriage - Carriage motor - motor that drives the carriage assembly |
| Q8401A-Motor_Scanner |
Motor Scanner - Scanner unit motor - drives the scanner unit to scan documents to be copied, fax, or scanned. |
| Q8401A-MTR_Srvce_Station |
Motor Service Station - Service station stepper motor (does not include cable) - moves the rack vertically in the service station assembly |
| Q8383-60010 |
Overlay - Control panel overlay - For the Photosmart C4480/C4500 All-in-One printer series |
| Q8401A-Overlay |
Overlay - Overlay unit which covers the control button or display (english overlay only), control panel or display sold seperately. |
| Q8401A-Pad_ADF |
Pad ADF - Pad separator - (located on ADF unit) assembled from plastic and rubber components; to help in separating sheet of media during faxing, scanning, or copying. |
| Q8401A-Pad_Tray |
Pad Tray - Pad separator - (located on tray) assembled from plastic and rubber components; to help in separating sheet of media during printing |
| 51634Y |
Paper - HP Premium Inkjet Paper - A size (8.5 x 11-inches) - 200 sheets |
| Q5458A |
Paper - Paper (Glossy) for DeskJet 300, DeskJet 640 Series, Designjet 30gp, DesignJet 130 Series |
| Q6568A |
Paper - Paper (Glossy) for DeskJet 660 Series, DeskJet 300, DesignJet 1055 Series, DeskJet 5550 Series |
| Q6569A |
Paper - Premium Plus Soft-Gloss Photo Paper (Matte) - A size (8.5 x 11-inches) - 25 sheets (North America) |
| Q7853A |
Paper - Paper (Glossy) for Business Inkjet 1200 Series, OfficeJet Pro K550 Series, Business Inkjet 2800 Series, DeskJet 9800 |
| Q8401A-PC_BRD |
PC Board - Ink cartridge carriage assembly pc board - includes carriage pc board only |
| Q8401A-PC_BRD_DC |
PC Board DC - Internal power supply board - power cable plugs on this assembly, remove covers to install pc board. |
| Q8401A-PC_BRD_Interface |
PC Board Interface - Internal print server lan interface board - plugs into peripheral eio. usefull for networking and multiple users. |
| Q8401A-Pinchwheel |
Pinchwheel - Pinch assembly kit - includes all required pinch wheels, pinchwheel mounts and springs |
| 8121-0889 |
Power Cord - Power cord (Black) - 2-wire, 18 AWG, 0.5m (1.6ft) long - Has straight (F) C7 receptacle (For 120V in North America, Opt. 953) |
| 8121-0890 |
Power Cord - Power cord (Black) - 2-wire, 17 AWG, 0.5m (1.6ft) long - Has straight (F) C7 receptacle (For 240V in India, Opt. 960) |
| 8121-0892 |
Power Cord - Power cord (Black) - 2-wire, 17 AWG, 0.5m (1.6ft) long - Has straight (F) C7 receptacle (Opt. 952) |
| 8121-0893 |
Power Cord - Power cord (Black) - 2-wire, 17 AWG, 0.5m (1.6ft) long - Has straight (F) C7 receptacle (For 240V in UK, Singapore, Malaysia, and Hong Kong, Opt. 955) |
| 8121-0894 |
Power Cord - Power cord (Black) - 2-wire, 17 AWG, 0.5m (1.6ft) long - Has straight (F) C7 receptacle (For use in Thailand and Brazil, Opt. 961) |
| 8121-0895 |
Power Cord - Power cord (Black) - 2-wire, 17 AWG, 0.5m (1.6ft) long - Has straight (F) C7 receptacle (For use in Europe, Opt. 954) |
| 8121-0897 |
Power Cord - Power cord (Black) - 2-wire, 17 AWG, 0.5m (1.6ft) long - Has straight (F) C7 receptacle (For use in Korea, Opt. 958) |
| 8121-0969 |
Power Cord - Power cord (Black) - 2-wire, 18 AWG, 0.5m (1.6ft) long - Has straight (F) C7 receptacle (USA and Canada, Opt. 953) |
| 8121-1055 |
Power Cord - Power cord (Black) - 2-wire, 17 AWG, 0.5m (1.6ft) long - Has straight (F) C7 receptacle (For use in Japan) |
| Q8401A-Power_Cord |
Power Cord - Power module power cord- wall outlet cable to power module only. does not include power module. |
| 0957-2231 |
Power Module - Power module - Input voltage 100-240VAC, 50/60HZ – Output voltage 32VDC, 600mA, 20 watts - Requires a separate 2-wire AC power cord (Universal) |
| Q8401A-Power_MDLE |
Power Module - World wide power module - includes power module and power module to printer cord - does not include outlet to power module cord |
| Q8401A-Power_MDLE_Assy |
Power Module Assy - World wide power module - includes power module and power module to printer cord - also, include outlet to power module cord |
| Q8401A-Power_Supply |
Power Supply - Power supply board (internal pwr supply unit in the office machine). |
| Q8401A-Power_Supply_BRD |
Power Supply Board - High voltage power supply board |
| Q8401A-Print_Mchnsm |
Print Mechanism - Print mechanism assembly - complete mechanism with carriage movement, paper picking and service station - does not include covers, printer base, print heads, ink cartridges, or any consumables. |
| Q8401-69006 |
Printer - Q8401-69006 |
| Q8401-69007 |
Printer - Q8401-69007 |
| Q8401A-Pulley |
Pulley - Paper pick up tray motor pulley. |
| Q8401A-Pulley_ADF |
Pulley ADF - ADF feeder motor pulley |
| Q8401A-Repair_InkJet |
Repair Service - Ship your product to us for a small diagnostic fee; and a professional service job. We will contact you with repair total and your diagnostic fee will be waived if unit is repaired. Service warranty is 30days labor and 90days for parts. Extended warranty option is available. |
| Q8401A-Rod_Carriage |
Rod Carriage - Carriage rod - shaft that the carriage assembly rides on |
| Q8401A-Rod_Scanner |
Rod Scanner - Scanner rod - shaft that the scanner assembly rides on |
| Q8401A-Roller_ADF |
Roller ADF - Feeder ADF roller for picking up paper from ADF unit. |
| Q8401A-Roller_Exit |
Roller Exit - Paper exit rollers - out put assembly. |
| Q8401A-Roller_Pickup |
Roller Pickup - Pick up roller assembly for paper bottom tray. Lower feed roller assembly - for lower paper input tray |
| Q8401A-Scanner |
Scanner - Copier scanner (optical) assembly - includes scanner assembly only scanner lens assembly (includes the charge coupled device (ccd)) the scanning lamp ADF analog processor board and ADF inverter board - major portion of the ADF main assembly. |
| Q8401A-Scanner_Assy |
Scanner Assembly - Copier scanner & glass assembly - includes the chassis assembly scanner lens assembly (includes the charge coupled device (ccd)) the scanning lamp ADF analog processor board and ADF inverter board - major portion of the ADF main assembly. |
| Q8401A-Scanner_Belt |
Scanner Belt - Scanner belt attaches from the scanner to the scanner motor. |
| Q8401A-Scanner_Cable |
Scanner Cable - Flex circuit cable which connects to the scanner assembly. also known as flat cable, this cable moves along with the scanner unit (side to side) as it scans documents. |
| Q8401A-Scanner_Motor |
Scanner Motor - Scanner driving motor |
| Q8401A-Scanner_Unit |
Scanner Unit - Scanner unit includes the entire scanner base, but not the ADF portion. |
| Q8401A-Sensor_ADF |
Sensor ADF - Photo-sensor assembly - includes the sensor and mounting bracket - paper pickup roller home position sensor - activated by the sensor flag on the pickup roller assembly - mounts on the front frame of the ADF paper pickup assembly |
| Q8401A-Sensor_Exit |
Sensor Exit - Exit media sensor sv |
| Q8401A-Sensor_Open |
Sensor Open - Door sensor assembly - open door sensor |
| Q8401A-Sensor_Out |
Sensor Out - OOPS sensor - out of paper sensor - detects the presence of the paper in the printer tray |
| Q8401A-Sensor_Spot |
Sensor Spot - Spot sensor assembly is attached to the carriage assembly. |
| Q8401A-Separator |
Separator - Pad separator - assembled from plastic and rubber components; to help in separating sheet of media during printing from bottom trays. |
| Q8401A-Guide |
Service Guide - Printer Reference Guide (not a service manual) - Contains information such as product information, operation overview, paper behavior, maintenance, ink safety, and removal / replacement of parts. This is not a service manual for technical repair. |
| Q8401A-Service_Station |
Service Station - Service station assembly - for conditioning the printheads when the carriage is in its home position |
| Q8401A-SLED_Assy |
SLED Assembly - Sled assembly - white plastic piece with spring, wipers and boot (assembly that the ink cartridge parks on) - mounts on top of the service station assembly |
| Q8401A-Slider |
Slider - Carriage base slider - plastic piece on the front end of the carriage that allows the carriage to slide side to side. |
| Q8401A-Speaker |
Speaker - Speaker assembly - includes speaker cable. |
| Q8401A-Spitton |
Spitton - Spittoon base - the bottom and main housing of the service station assembly - holds any residual ink from the print cartridge cleaning process |
| Q8401A-Spring_Cmprsn |
Spring Compression - Compression spring - on pulley wedge, for carriage belt tension |
| Q8401A-Trailing_Cbl |
Trailing Cable - Trailing cable for scanner - cable connects from scanner to pc board. |
| Q8408-60020 |
Tray - Paper tray assembly - Photosmart C4580 All-in-One printer series |
| Q8401A-Tray_Assy |
Tray Assembly - Paper input tray assembly for loading paper (bottom). |
| Q8401A-Tray_Assy_CVR |
Tray Assembly Cover - Tray cover - the top cover for the paper pick up tray unit. |
| Q8401A-Tray_Base |
Tray Base - Tray base- bottom base of the paper input tray. |
| Q8401A-Window |
Window - Top/front access door assembly - print cartridge access door window. |
View service parts
