Lexmark parts list for 10G0100 Lexmark Laser T630 Printer
56P1326
Arm - Pick arm assembly (250-sheet) 000/010
56P1352
Arm - MPF pad/separator arm assembly
99A0062
Bracket - Bracket, level sensor
13A0297
Cable - Cable, Coax 9 pin-to-BNC
56P1382
Cable - Int. card/autocomp card cable (paper low/out sensors)
56P1383
Cable - Cable, autoconnect bottom
56P1384
Cable - Cable, main drive motor
56P1385
Cable - Cable, front harness (HVPS/input sensor/toner sensor)
56P1388
Cable - Cable, mirror motor, 000/010
56P1390
Cable - Cable, system board to fuser board
56P1396
Cable - Printhead assembly (includes all cables), 000/010
56P1399
Cable - Smart cartridge contact assembly w/cable
56P1400
Cable - Cable, autoconnect top, 000/010
56P1405
Cable - Cable, AC fuser lamp to LVPS
12A7360
Cartridge - Lexmark Cartridge Standard Yield, 5,000 pages
12A7362
Cartridge - Yields up to 21000 pages Black Toner Cartridge High Yield
12A7365
Cartridge - Black Toner Cartridge Extra High Yield Yields up to 32000 pages
12A7460
Cartridge - Black Return-Program Toner Cartridge. Yields up to 5000 pages
12A7462
Cartridge - Lexmark Black Toner Cartridge (12A7462), High Yield, Return Program
12A7465
Cartridge - toner cartridge - black - 32,000 pages @ 5% coverage
12A7468
Cartridge - Lexmark Black Toner Cartridge for Label Applications (12A7468), High Yield, Return Program
12A7469
Cartridge - Lexmark Black Toner Cartridge for Label Applications (12A7469), Extra High Yield, Return Program
24B2540
Cartridge - Lexmark Cartridge High Yield, 21,000 pages
56P1100
Cartridge - Cartridge, empty shipping
56P1300
Cover - Cover, fuser wick assembly
56P1301
Cover - Cover assembly, laser assembly, 250-sheet output, 000/010
56P1303
Cover - Upper front cover with Lexmark logo
56P1306
Cover - Cover, right side, 250-sheet output, 000/010
56P1309
Cover - Cover assembly, lower front
56P1341
Cover - Cover, INA flat (blank)
56P1348
Cover - Fuser cover assembly
56P1356
Cover - Cover, clear bezel, 000/010
56P2122
Cover - Cover, left door, 250 1-slot, 000/010
99A2074
Cover - Cover assembly, redrive cap
56P1334
Deflector - Deflector, inner, 000/010
99A2092
Deflector - Deflector Assembly, MPT
56P1351
Door - Door assembly, redrive 250-sheet
99A0655
Door - Door assembly, front
99A2151
Drive Assembly - Redrive assembly, 250 in/250 out
56P1317
Duct - Duct, left stacker, 250-sheet, 000/010
56P1414
Duplexer - 250-sheet Duplex Unit, complete assembly
56P1324
Flag - Flag, paper out 250-sheet tray, 000/010
99A1613
Flag - Flag, output paper level
56P1417
Flash Card - 16MB Flash Card
56P1418
Flash Card - 32MB Flash Card
56P1427
Flash Card - Optra Forms 32MB Flash card
56P1428
Flash Card - Optra Forms 16MB Flash card
56P1320
Frame - Right side frame assembly
56P1364
Fuse - Fuse, for 220 V ac HVPS 6.3 a/250V (fuse F2), 000/010
56P1365
Fuse - Fuse, for 110 V ac LVPS 5 a/250V (fuse F1), 000/010
56P2542
Fuser Assembly - Fuser assembly w/115V lamp, 000/010/200/210
56P2543
Fuser Assembly - Fuser assembly w/100V lamp, 000/010/200/210
56P2544
Fuser Assembly - Fuser assembly w/220V lamp, 000/010/200/210
56P2162
Gear - Gear, bevel with grease packet and washer
56P1330
Gearbox - Gearbox, w/motor, 000/010
56P1332
Gearbox - Gearbox, w/motor, 000/010, 200/210
56P1419
Hard Drive - Hard disk with adapter 20+GB
56P1424
Hard Drive - Optra Forms Hard Disk with adapter (20+GB)
56P1305
Hinge - Hinge, upper front cover
99A1797
Idler - Idler pulley, belt tension
12G9707
Kit - Service Information and Training Kit
12G9720
Kit - Service Information and Training Kit
12G9782
Kit - Service Information and Training Kit
40X4308
Kit - Pick roll assembly (2 per package)
56P1409
Kit - 120v usage kit for IBM1352
56P1413
Kit - T630, T632 Fuser Maintenance Kit 100V
56P1753
Kit - Kit, operator panel overlay-English, Brazilian Portuguese, French, and Spanish
56P1754
Kit - Kit, operator panel overlay-Dutch, French, German, and Italian
56P1757
Kit - Kit, operator panel overlay-Polish, Russian, and Turkish
56P1758
Kit - Kit, operator panel overlay-WW English and Spanish
56P2542
Kit - Fuser assembly w/115V lamp, 000/010/200/210
7371454
Kit - Relocation kit, 250/250-sheet printer
7371455
Kit - Relocation kit, 500/250-sheet printer
99A0392
Kit - Kit, door switch spring and bumper
56P1362
Lamp - Lamp, 115V, 000/010/200/210
56P1363
Lamp - Lamp, 220V, 000/010/200/210
56P1412
Maintenance Kit - T630, T632 Fuser Maintenance Kit 220-240V
56P1413
Maintenance Kit - T630, T632 Fuser Maintenance Kit 100V
12G9328
Manual - T63x Service Manual
56P1444
Network - Card assembly, communications, non-network
56P1445
Network - Card assembly, communications, network
56P3080
Network - System board assembly (non-network), 000 includes 56P1444
99A2077
Pad - Pad, machine mounting
56P1310
Panel - Operator panel assembly 110V
56P1311
Panel - Operator panel assembly 220V
56P0557
PC Board - Card assembly, tray
56P1340
PC Board - Interconnect board assembly 1 slot, 000/010
56P1350
PC Board - Board, input tray (ITC)
56P1406
PC Board - Card assembly, paper wt/paper low/out sensor
56P1436
PC Board - RS-232 Serial Interface Card
56P1437
PC Board - Parallel 1284-B interface card
56P1850
PC Board - Bar Code Card T63x
56P1864
PC Board - Card for PRESCRIBE Emulation T63x
99A1806
PC Board - Card assembly, 2000 option control
99A0121
Plate - 250-sheet tray wear plate
99A2020
Plate - Transfer plate assembly
1339539
Power Cord - Power cord;1.8 m, 6 ft. Israel
1339545
Power Cord - Power cord;2.5 m, 8 ft. Right angle, Argentina (HV)
1339549
Power Cord - Power cord; 1.8 m, 6 ft. Right angle, Brazil (HV)
1339551
Power Cord - Power cord;1.8 m, 6 ft. Right angle, Brazil (LV)
1339552
Power Cord - Power cord;2.5 m, 8 ft. Right angle, Japan
1339554
Power Cord - Power cord;2.5 m, 8 ft. Right angle, Japan
1339557
Power Cord - Power cord; 1.8 m, 6 ft. Right angle, Korea
1342514
Power Cord - Power cord;2.5 m, 8 ft. Right angle, US, Canada, Latin America (LV)
1342530
Power Cord - Power cord;2.5 m, 8 ft. Right angle, Europe, Middle East, Indonesia, Africa (HV)
1342534
Power Cord - Power cord;2.5 m, 8 ft. Right angle, Chile (HV), Italy, Uruguay
40X0255
Power Cord - Power cord 2.5 m 8 ft. Right angle Argentina Paraguay Uruguay
40X0283
Power Cord - Power cord; 2.5 m, 8 ft. Japan
40X0284
Power Cord - Power cord; 1.8 m, 6 ft. Right angle, Taiwan
43H5248
Power Cord - Power cord;2.5 m, 8 ft. Right angle, US, Canada, Latin America (LV)
43H5546
Power Cord - Power cord; 2.5 m, 8 ft. Right angle, PR China (HV)
56P1369
Power Supply - LVPS, 110 V ac, 000/010
56P1372
Power Supply - HVPS, 220 V ac, 000/010
56P1375
Power Supply - Power supply, high voltage
56P1741
Print Server - MarkNet N2100t Token Ring internal print server
99A2093
Restraint - Restraint, back 500-sheet tray
40X4308
Roller - Pick roll assembly (2 per package)
99A0070
Roller - Pick roll assembly
99A0179
Roller - Transfer roll assembly
56P1361
Sensor - Toner sensor assembly
56P1402
Sensor - Narrow media sensor
56P3313
Sensor - Narrow media sensor
99A2071
Sensor - Sensor, MPF paper out
56P0159
Service Parts - Coax/Twinax Adapter for SCS
56P1327
Service Parts - Alignment assembly, paper feed
56P1357
Service Parts - Transfer roll assembly
56P1415
Service Parts - Wiper assembly, wet
56P1742
Service Parts - MarkNet N2101e Ethernet 10/100BaseTX internal print server
99A1150
Service Parts - High-Capacity Output Stacker, complete assembly
99A1173
Service Parts - StapleSmart Finisher, complete assembly T63x
99A1792
Service Parts - Stacker, assembly paper path upper
99A0134
Shaft - Shaft, power takeoff 250
99A0272
Shaft - Drive Shaft 250-sheet
99A0447
Shaft - 550- 500-sheet drive Shaft
99A2081
Shaft - Parts packet, developer drive shaft, coupler gear #55
99A2517
Shaft - Shaft assembly, upper exit
56P1343
Shield - Shield, inner assembly, 1 slot. 000/010
56P1345
Shield - Shield, outer 1 slot, 000/010
56P2404
Shield - Shield, INA flat non-network
56P2405
Shield - Shield, INA flat network
56P1314
Shroud - Shroud 250 Fan (T630 T630D X630 MFP)
56P2407
Solenoid - Multipurpose feeder frame assembly with solenoid
56P2540
Spring - Bellcrank spring - 500-sheet tray
99A0063
Spring - Switch Activate Spring
99A0275
Spring - Power Takeoff Spring
99A1929
Spring - Bellcrank spring - 250-sheet paper tray
99A2019
Spring - Spring, cartridge hold down
56P2797
Support - Support, paper assembly
99A2018
Support - Support, left lower stacker
99A2021
Support - Support, right stacker plate
56P1395
Switch - Switch, cover closed w/cable assembly
99A2502
Switch - Switch, stapler access door assembly
99A2485
Tray - 400-sheet (UAT) Tray
56P1409
USAGE KIT - 120v usage kit for IBM1352
Laser T630 Printer parts list
