HP parts list for 33471B HP LaserJet IIP

RA1-7629-000CN Arm - Paper guide arm (Black) - Small curved side arms at MP input

RA1-7661-000CN Arm - Sensor arm - For sensing paper in the lower cassette base

RA1-7592-000CN Button - Release button - Unlocks paper path door

17255D Cable - RS-232C serial cable - 25-pin (M) to 25-pin (F) - 1.2m (3.9ft) long

24540-80010 Cable - Centronics (parallel) cable - 36-pin (M) to 25-pin (M) - 2.0m (6.6ft) long

5063-1256 Cable - IEEE-1284 Bi-Tronics parallel cable - DB-25 (M) connector (type A) to 36-pin Centronics (M) connector (type B) - 2.0m (6.6ft) long

5063-1257 Cable - IEEE 1284 Bi-Tronics parallel cable - DB-25 (M) connector (type A) to 36-pin Centronics (M) connector (type B) - 3.0m (9.8ft) long

C2951A Cable - IEEE-1284 Bi-Tronics parallel cable - DB-25 (M) connector (type A) to 36 pin Centronics (M) connector (type B) - 3.0m (9.8ft) long

RF1-2427-000CN Cable - AC connector cable assembly - For fusing assembly

RG1-1602-000CN Cable - Cable assembly - From AC power supply to fusing assembly

RG1-1608-000CN Cable - Cable assembly - Includes pickup solenoid

RG1-1609-000CN Cable - Cable assembly - Has eight connectors

RG1-1612-000CN Cable - Sensor cable assembly

RH2-5104-000CN Cable - Fiber optic cable - From DC controller to fiber optic lens

SG4-6271-000CN Cable - Cable assembly for HP LaserJet II

RA1-7628-000CN Cap - Spring cap for HP LaserJet IIIP

5090-3379 Cleaner - Toner cleaning cloth - Specially treated cloth for absorbing toner or Ink (1 per package) - Ideal for cleaning up toner spills and Ink for your plotter / copier / printer

RG1-1780-000CN Contact - High voltage toner cartridge contact assembly - With cable

RH6-0010-000CN Control Panel - Control panel assembly - Includes display and keypad

RA1-7520-000CN Cover - Right side cover - Has cutouts for font door and power switch

RA1-7522-000CN Cover - Left side cover

RA1-7672-000CN Cover - Stop cover - Located on rear of optional lower cassette base

RA1-7673-000CN Cover - Replacement top cover - Covers top part of tray extending from lower casette base

RF1-2420-000CN Cover - Right Side Cover - For (optional) lower cassette base

RF1-2421-000CN Cover - Left side cover - For (optional) lower cassette base

RF1-2490-000CN Cover - Top cover - Does NOT include any attaching parts

RG1-1809-000CN Cover - Top cover assembly - Includes case pieces and control panel

RA1-8244-000CN Deflector - Paper deflector - Directs paper to top cover or face-up tray

RY7-0017-000CN Diode - Diode upgrade kit - For fusing assembly - Set includes three diodes - 10 sets per kit

RA1-7514-000CN Door - Font cartridge door - Spring loaded cover - On right side

RG1-2622-000CN Door - Paper path door assembly (120V, 60Hz) - Complete front of printer

RG1-2623-000CN Door - Paper path door assembly (240V, 50Hz) - Complete front of printer

RH7-1121-000CN Fan - Tubeaxial fan for HP LaserJet IIIP

92296T Film - Film (Transparency) for LaserJet II, LaserJet III, LaserJet 4 Series, LaserJet 4L Series

92296U Film - Film (Transparency) for LaserJet 33x0 MFP Seriess, LaserJet 4100 Series, LaserJet P2xxx Printer, Color LaserJet CM1015 MFP

RA1-7453-000CN Foot - Rubber foot - Replacement rubber foot for the bottom of the printer

XH9-0059-000CN Foot - Rubber foot - Replacement rubber foot for the bottom of the printer (three used)

VD5-0185-001CN Fuse - Fuse - 5A, 125V max

WD1-0222-000CN Fuse - Fuse - 3.15A, 250V max

33471-69018 Fuser Assembly - Fusing assembly (120V, 60Hz) - Bonds toner to paper by heat

33471-69019 Fuser Assembly - Fusing assembly (240V, 50Hz) - Bonds toner to paper by heat

5181-2252 Fuser Assembly - Fusing assembly (For 240V, 50Hz operation) - Bonds the toner to the paper with heat - In quantity price break packaging (Contains five new fusing assemblies)

5181-2253 Fuser Assembly - Fusing assembly (For 240V, 50Hz operation) - Bonds the toner to the paper with heat - In quantity price break packaging (Contains ten new fusing assemblies)

RG1-1776-000CN Gear - Gear cluster assembly (Large)

RS1-0287-000CN Gear - Dual gear - 27/21 tooth - On right side of fusing assembly

RS1-0292-000CN Gear - Gear - 27 tooth - Drives transfer charge roller

RG1-1777-000CN Gear Assembly - Gear assembly - Right side

RG1-1833-000CN Gear Assembly - Drive gear assembly - Two black 15-tooth gears on white mounting plate

RA1-7543-020CN Guide - Memory board guide - Supports optional memory boards

RF1-2400-050CN Guide - Paper guide plate (Black metal with 4-inch by 1/4-inch felt strip)

RG9-0681-000CN Guide - Roller guide - Paper guide for transfer roller

XA9-0494-000CN Hardware - Screw - For installing lower cassette base assembly

33481-67909 Kit - Self paced training kit for IIP, IIIP, IIP+ LaserJet printers - Includes service manual, CBT (computer based training), and one test

92296E Label - LaserJet printer shipping labels - 8.47cm (3.33in) x 10.2cm (4.00in) labels - Six per sheet - 100 sheets per box

92296F Label - LaserJet printer return address labels - 1.27cm (0.50in) x 4.45cm (1.75in) labels - 80 per sheet - 25 sheets per box

92296G Label - LaserJet printer file folder labels - 1.69cm (0.67in) x 8.73cm (3.44in) labels - 30 per sheet - 25 sheets per box

92296H Label - LaserJet printer labels for 3.5-inch diskettes - 7.00cm (2.75in) x 7.00cm (2.75in) labels - Nine per sheet - 70 sheets per box

92296J Label - LaserJet printer labels for 5.25-inch diskettes - 3.81cm (1.50in) x 10.2cm (4.00in) labels - 12 per sheet - 70 sheets per box

92296K Label - LaserJet printer full sheet label - A size (8.5 x 11-inches) label - One per sheet - 100 sheets per box

92296L Label - LaserJet/DeskJet printer labels - 9.91cm (3.90in) x 3.81cm (1.50in) labels on A4 size (21.0cm x 29.7cm) sheet - 14 per sheet - 100 sheets per box

92296M Label - LaserJet/DeskJet printer labels - 9.91cm (3.90in) x 3.38cm (1.33in) labels on A4 size (21.0cm x 29.7cm) sheet - 16 per sheet - 100 sheets per box

92296N Label - LaserJet/DeskJet printer labels - 6.35cm (2.52in) x 3.81cm (1.50in) labels on A4 size (21.0cm x 29.7cm) sheet - 21 per sheet - 100 sheets per box

92296P Label - LaserJet/DeskJet printer labels - 10.0cm (3.94in) x 5.10cm (2.01in) labels on A4 size (21.0cm x 29.7cm) sheet - 10 per sheet - 100 sheets per box

92296R Label - LaserJet/DeskJet printer labels - 20.0cm (7.86in) x 28.9cm (11.4in) labels on A4 size (21.0cm x 29.7cm) sheet - One per sheet - 100 sheets per box

RF1-3303-000CN Lamp - Fusing heat lamp (120v, 60Hz)

RF1-3304-000CN Lamp - Fusing heat lamp (240v, 50Hz)

RG1-1772-000CN Lens - Focusing lens assembly - Black plastic with clear curved lens

RA1-7562-000CN Lever - Paper sensing lever - In right side of paper feed area

RA1-7588-000CN Lever - Paper sensing lever - In fusing assembly

RA1-7717-000CN Lever - Paper sensor lever - On left side of paper feed area

33472-67901 Lower Cassette - Optional lower cassette (letter size) upgrade - Base assembly parts only - Does NOT included paper tray (33472A)

33472-67902 Lower Cassette - Optional lower cassette (A4 size) upgrade - Base assembly parts only - Does NOT included paper tray (33472AB)

33481-69007 Maintenance Kit - Maintenance Kit (120V) - Includes Fusing Assy, Separation. Hewlett Packard LaserJet IIP IIIP series models.

33481-69008 Maintenance Kit - Maintenance kit (220V)

33471-90901 Manual - 33471A LaserJet IIP printer users manual

33471-90905 Manual - 33471A/C2007A LaserJet IIP/IIP+ technical reference manual

33471-90917 Manual - 33471A LaserJet IIP printer users manual (German)

33471-90919 Manual - 33471A LaserJet IIP printer users manual (French)

33471-90922 Manual - 33471A LaserJet IIP software application notes manual

33481-90951 Manual - Manual for LaserJet II, LaserJet III

5021-8943 Manual - LaserJet quick reference guide - Covers LaserJet Classic, II series, III series, 4 sereis, 5 series, 6 series and 5Si - Volume 1 of 2 volume set

5090-3390 Manual - LaserJet Quick Reference Guide - Covers 1100, 2100, 3100, 4000, 5000 and 8000 series printeres - Volume 2 of 2 volume set

C6072-60301 Manual - HP-GL/2 driver software for AutoCAD - For DOS and Windows 3.1/95/NT 4.0 - On 3.5-inch 1.44MB floppy disks (English)

33474-69004 Memory - 1MB memory expansion board

33474B Memory - 1MB memory expansion board - For LaserJet IIP, III, IIIP, IIID

33475-69011 Memory - 2MB memory expansion board

33475B Memory - 2MB memory expansion board - For LaserJet IIP, III, IIIP, IIID

J2382-69003 Module - External JetDirect LAN interface module with EtherTwist (10Base-T) and ThinLAN (10Base-2) connectors

J2590-69001 Module - External JetDirect LAN interface module with RJ-45 connector for EtherTwist (10Base-T) or 100VG/802.12 input and three parallel (DB-25) output connectors

J2592-69001 Module - External JetDirect LAN interface module with EtherTwist (10Base-T) connector

J4102-61021 Module - External JetDirect LAN interface module with EtherTwist (10Base-T) connector

J4102-69022 Module - External JetDirect LAN interface module with EtherTwist (10Base-T) connector

RG1-1771-000CN Motor - Scanner motor assembly - Includes motor drive board

RH7-1094-000CN Motor - Main motor assembly

33481-40003 Overlay - Control panel overlay - For alternate language (Italian)

RG1-1912-080CN Pad - Separation pad - Rectangular pad - Behind pickup roller

RF1-2431-000CN Panel - Rear panel - Has bezel for I/O connector panel

33417-67901 PC Board - AppleTalk board with dual I/O ports

33471-67905 PC Board - Rear dual port board assembly - Mounted on sheet metal cover

33471-69001 PC Board - Formatter (Main Logic) board

33471-69002 PC Board - DC controller board

RG1-1596-000CN PC Board - Lower cassette board

RG1-1604-000CN PC Board - Density adjust board - Includes cable assembly

RG1-1769-020CN PC Board - Laser driver board - Includes laser assembly

RG1-2664-000CN PC Board - High voltage power supply board

RG9-0696-000CN PC Board - High voltage power supply board

J2590A PC Board Interface - External JetDirect LAN interface module with RJ-45 connector for EtherTwist (10Base-T) or 100VG/802.12 input and 3 parallel (DB-25) output connectors

J2591-69001 PC Board Interface - External JetDirect LAN interface module with EtherTwist (10Base-T) and ThinLAN (10Base-2) connectors

J2591A PC Board Interface - External JetDirect LAN interface module and power module - Has EtherTwist (10Base-T) and ThinLAN (10Base-2) connectors

J2594-69001 PC Board Interface - External JetDirect token ring interface module with DB-9 and RJ-45 input connectors and three parallel (DB-25) output connectors

J3258-61041 PC Board Interface - External JetDirect 170X LAN interface module - Interfaces a parallel printer to an ethernet 10Base-T (RJ-45) LAN

J3258B PC Board Interface - External JetDirect 170X LAN interface module - Interfaces a parallel printer to an ethernet 10Base-T (RJ-45) LAN

J3264A PC Board Interface - HP JetDirect 500X external token ring print server module - Interfaces up to 3 parallel printers to a token ring (DB-9 or RJ-45) LAN

J3265-69001 PC Board Interface - External JetDirect LAN interface module with EtherTwist (10Base-T and ThinLAN) (10Base-2) input connectors and three parallel (DB-25) output connectors

J3265G PC Board Interface - HP JetDirect 500X external token ring print server module - Interfaces up to 3 parallel printers to an ethernet 10Base-T (RJ-45), 10Base2 (BNC), or 100Base-TX (RJ-45) LAN

J4101B PC Board Interface - HP JetDirect 300X external print server module (10Base-T and 100Base-TX) - Connects between printer parallel port and LAN network

J4102B PC Board Interface - External JetDirect LAN interface module with EtherTwist (10Base-T) connector

RA1-7499-000CN Pin - Hinge pin (Clear plastic)

33439-69001 PostScript - Postscript cartridge

8120-4211 Power Cord - Power cord (Mint Gray) - 17 AWG, 2.0m (6.6ft) long - Has straight (F) receptacle (for 240V in South Africa and India)

0957-2340 Power Module - Wall mount power supply module - 120VAC input 60Hz power supply AC DC 15W UNIVERSAL ADAPTER Power module (wall mount)- Input voltage 100-240 VAC - Output voltage 12 VDC, 15 watts output, 1.0A - for Jet Direct power and other accessories.

0957-2481 Power Module - Pwra brk uni 12vdc 15w

0950-2623 Power Supply - Switching power supply (Delta DPS-158ABA) - 100-240VAC input, 47-63Hz - Four DC outputs (5.15V, +12V, -12V, 24V) - 158 watts - Includes upgrade sticker

33471-69017 Power Supply - Main power supply assembly - 120VAC, 60Hz

RG1-1910-020CN Power Supply - Power supply assembly - 240VAC, 50Hz - Main power supply

RH3-2083-000CN Power Supply - Main power supply assembly - 120VAC 60Hz

33471B-Repair_LaserJet Repair Service - Ship your product to us for a small diagnostic fee; and a professional service job. We will contact you with repair total and your diagnostic fee will be waived if unit is repaired. Service warranty is 30days labor and 90days for parts. Extended warranty option is available.

RG1-1781-000CN Rod - Interlock push rod - Also opens shutter on toner cartridge

RA1-7583-030CN Roller - Lower pressure roller - Hard rubber roller - Located in fusing assembly

RA1-7627-000CN Roller - Transfer charge roller (Black) - In paper path door assembly

RA1-7654-000CN Roller - Feed roller assembly - For (Optional) lower cassette input

RA1-7674-000CN Roller - D-shaped pickup roller - Located in lower cassette assembly

RA1-7708-040CN Roller - Delivery roller - Has four 'Foam' rollers - For (Face down) top of printer paper output

RA1-7824-000CN Roller - D-shaped pickup roller - Located in lower cassette assembly

RF1-2394-000CN Roller - Input feed roller/shaft (Only) - Has drive gear between the two feed rollers

RF1-2491-000CN Roller - Hard roller/spring - Rolls against top output roller

RF1-2505-000CN Roller - Fusing roller - Hollow roller - Heat lamp goes in its core

RG1-1778-000CN Roller - Feed roller assembly - Roller assembly after paper pickup roller

RG1-1791-070CN Roller - Delivery roller assembly - Has four 'Foam' rollers - For (Face down) top of printer paper output

RG1-1792-000CN Roller - Pickup roller assembly - For multipurpose input tray

RG1-1834-000CN Roller - Delivery roller assembly - Includes three dual knobbed rollers - For (face up) front of printer paper output

RY7-5080-000CN Sensor - Photo sensor - Includes (one photo sensor) photo sensors PS 1,3,5 and 6

WG8-0323-000CN Sensor - Photo sensor for HP LaserJet IIIP

33471B-Manual_Laser Service Manual - Printer Service Manual - Includes troubleshooting, error messages, paper jams, parts and parts diagrams.

RA1-7655-000CN Shaft - Pickup roller shaft - Does NOT include any 'D-shaped' rollers

C6072-60304 Software - HP-GL/2 driver software for AutoCAD - For DOS and Windows 3.1/95/NT 4.0 - On 3.5-inch 1.44MB floppy disks (German)

C6072-60305 Software - HP-GL/2 driver software for AutoCAD - For DOS and Windows 3.1/95/NT 4.0 - On 3.5-inch 1.44MB floppy disks (French)

C6072-60306 Software - HP-GL/2 driver software for AutoCAD - For DOS and Windows 3.1/95/NT 4.0 - On 3.5-inch 1.44MB floppy disks (Spanish)

C6072-60307 Software - HP-GL/2 driver software for AutoCAD - For DOS and Windows 3.1/95/NT 4.0 - On 3.5-inch 1.44MB floppy disks (Italian)

RF1-2406-000CN Solenoid - Lower cassette solenoids (SL2 and SL3) - Includes the pickup solenoid, the feed solenoid, and the cable harness assembly

RH7-5025-000CN Solenoid - Pickup solenoid (SL2) - For lower cassette pickup roller

RH7-5026-000CN Solenoid - Feed solenoid (SL3) - For lower cassette paper feed

RA1-7518-000CN Spring - Torsion spring for font cartridge door

RS1-2244-000CN Spring - Guide Plate pressure spring - Located on bottom of paper path door

RA1-7519-000CN Stop - Flip-up paper stop on top cover - For paper output

RG1-1793-000CN Support - Roller support - Supports left hand side of transfer roller

RG1-1794-000CN Support - Roller support - Supports right side of transfer roller

RH7-6017-000CN Switch - Power switch (rocker)

RF1-2405-000CN Thermistor - Thermistor assembly (TH1) - Includes cable

RF1-2483-000CN Thermoswitch - Thermoswitch (TS1) - 175 degree Celsius

RF1-2484-000CN Thermoswitch - Thermoswitch (TS2) - 210 degree Celsius

33481-90985 Training - Additional self paced computer based training - Includes student lab guide, return mailer, and labels - For LaserJet

92275F Tray - HP Envelope tray - Envelope input tray for LaserJet IIP, II Plus, IIIP - For optional lower cassette 33472A - Holds 20 COM10, DL, C5, or Monarch size envelopes

RA1-7630-000CN Tray - 'Face-Up' paper output tray - Hooks on front of printer

RA1-7631-000CN Tray - Legal extension tray - Attaches to multipurpose input tray

RG1-1806-070CN Tray - Multi-Purpose input tray - Fold down front cover

RA1-7515-000CN Window - Display window (Clear Plastic)

LaserJet IIP parts list
