Xerox parts list for 6204-Wide-Format 6204 Wide Format

101K46220 Assembly - Inlet and Breaker Assembly

130K62710 Assembly - LPH Assembly

802K67750 Assembly - Console Assembly (REP 2.1)

055K28650 Baffle - Upper Exit Baffle Assembly (REP 10.2)

055K28730 Baffle - Take Away Baffle

055K30130 Baffle - Upper Baffle

023E21500 Belt - Belt

423W03154 Belt - Belt

423W48154 Belt - Belt

423W72455 Belt - Belt

033K94710 Blade - Metering Blade (REP 9.11)

033K94740 Blade - Cleaner Blade (REP6.4.1)

014E51340 Block - Block

014E55930 Block - Block

014K82160 Block - Spring Block

014K82210 Block - RFC Takeaway Roll Block

117K36500 Cable - IOT USB Cable

117K36550 Cable - RFC Flat Cable

021E98990 Cap - Left End Cap

021E99000 Cap - Right End Cap

052K92220 Cartridge - Toner Pipe

050E89850 Catch - Catch Tray

121E84820 Catch - Catch Magnet

121E86350 Catch - Catch Magnet

121E89690 Catch - Catch Magnet

121E89780 Catch - Magnet

849E38520 Catch - Catch Magnet Bracket

101E15040 Chassis - Breaker Chassis (P/O Item 1)

054E26510 chute - Lower Exit Chute (REP 10.3)

054K30050 chute - Inlet Chute

908W00916 Circuit Breaker - Circuit Breaker (CB1-1)

005K07210 Clutch - Friction Clutch

121K34540 Clutch - (SCC) Manual Feed Clutch (REP99.1.1)

121K34890 Clutch - RFC Takeaway Clutch (REP1.1.1)

005E19270 Collar - Collar

913W02320 Connector - Inlet Connector

117K36420 Cord - BCR Cord

117K36460 Cord - BTR Cord

117K36470 Cord - DTS Cord

802E72100 Cover - Left Lower Cover (REP 16.1)

802E72120 Cover - I/F Cover

802K68190 Cover - Left Upper Cover (REP 16.3)

802K68200 Cover - Front Upper Cover (REP 16.4)

802K68220 Cover - Rear Cover Assembly (REP 16.8)

802K68251 Cover - Right Lower Cover Assembly

802K68330 Cover - Right Upper Cover (REP 16.7)

802K71000 Cover - Right Lower Cover (REP 16.5)

802K76780 Cover - Rear Lower Cover (REP 16.9)

037K90800 Cutter - Cutter

110K11370 Cutter - Cutter Interlock Switch (S1-7, S1-8)

004E12820 Damper - Motor Damper

117K36450 Developer - Developer Bias Cord

802K67450 Developer - Developer Assembly (REP 9.10)

809E58190 Developer - Developer Tension Spring

802K71220 Door - Front Left Door

802K71230 Door - Front Right Door

110K10520 Drawer - RFC 1 Drawer Open Switch

809E36250 Extension - Extension Spring

127K29331 Fan - LVPS Fan

960K08750 Filter - AC Filter PWB

006K23780 Finger - Finger Shaft

019K06900 Finger - PR Stripper Finger (REP 9.9)

802E72150 Foot - Foot Cover

019E92900 Fuse - Fuser Stripper Finger

022K70580 Fuse - Fuser Exit Roll (REP 10.6)

059K33800 Fuse - Fuser Roll (REP 10.10)

802K77120 Fuse - Fuser Cover

007P60934 Gear - Gear (Spur 40T)

407W07421 Gear - Gear

499W14432 Gear - Pulley (32T)

038K88450 Guide - Inlet Guide

038K88110 Guide Paper - Paper Guide

121K35080 Hard Drive - Hdd (40gb) (Rep 3.1)

962K24220 Harness - Inlet Harness

962K24610 Harness - Sensor Wire Harness

110E10660 Heater - Paper Heater Switch

126E02260 Heater - L/H Paper Heater (HTR7-1, HTR7-4), Center Paper Heater (HTR7-2, HTR7-5), R/H Paper Heater (HTR7-3, HTR7-6)

126E93150 Heater - L/H Paper Heater (HTR7-1, HTR7-4), Center Paper Heater (HTR7-2, HTR7-5), R/H Paper Heater (HTR7-3, HTR7-6) 220V (EO)

022K67500 Housing - BTR Housing (REP 9.6)

802K67010 Housing - Xeroghraphics Housing

802K67150 Housing - Toner Housing

020E98790 Idler - Idler Pulley

499W17061 Idler - Idler Pulley

110E97990 Interlock - Front Interlock Switch

815E08940 Interlock - Interlock Switch Actuator

112E00960 Inverter - CIS Inverter

802E86990 Key - Key Face Cover

003E84580 Knob - Knob

826E12420 Knob - Knob Screw

849E34160 Lamp - Lamp Bracket

003E56250 Latch - Left Latch

003E56260 Latch - Right Latch

802K83370 LCD - LCD Face Cover

960K00940 Memory - Memory PWB

127K31870 Motor - Fuser Drive Motor (MOT10-1) (REP 10.4)

127K33340 Motor - Feeder Motor (MOT8-1, MOT8-3)

127K40250 Motor - IIT Drive Motor (MOT6-1)

960K01560 Motor - RFC Motor PWB

960K01570 PC Board - IOT Control PWB

960K02010 PC Board - CP Control PWB-NVRAM

960K03160 PC Board - IIT Control PWB

059E92390 Pin - Pinch Roll

024K93010 Plate - Lower Tie Plate

090E91630 Platen - White Platen

117E17420 Power Cord - Power Cord

105E15200 Power Supply - 24b Lvps

105E16250 Power Supply - 3.5 Lvps 110v (Naco)

105E16260 Power Supply - 3.5 Lvps 220v (Eo)

105E16270 Power Supply - 5b1,5b2 Lvps 110v (Naco)

105E16280 Power Supply - 5b1,5b2 Lvps 220v (Eo)

105E16290 Power Supply - Lvps 24v (24a)

105K20900 Power Supply - Hvps

007K85260 Pulley - RFC 2 Gear and Pulley

020E37560 Pulley - Drum Pulley

499W14426 Pulley - Pulley

801K15630 Rail - Left Rail

801K15640 Rail - Right Rail

059K36220 Registration - Registration Roll

960K06220 Relay - AC Relay PWB

009E58670 Ring - Torsion Spring

013E19240 Ring - Bearing

013E96820 Ring - Ball Bearing

013P60672 Ring - Bearing

013P61299 Ring - Bearing

413W11460 Ring - Sleeve Bearing

413W11660 Ring - Sleeve bearing (REP 90.17)

413W11860 Ring - Bearing

413W12350 Ring - Ball Bearing

413W17559 Ring - Bearing

413W75959 Ring - Powdered Metal Bearing

413W77359 Ring - Bearing

809E22970 Ring - BTR Spring

809E33510 Ring - Nip Spring

809E56630 Ring - Compression Spring

809E56640 Ring - Tension Spring

809E56650 Ring - Earth Spring

809E56800 Ring - Tension Spring

809E58220 Ring - Tension Spring

809E58370 Ring - Tension Spring

809E61100 Ring - Tension Spring

126K17750 Rod - Center Heat Rod 240V (REP 10.5)

126K17760 Rod - Side Heat Rod 240V (REP 10.5)

126K17770 Rod - Sub Heat Rod 240V (REP 10.5)

016E95410 Roller - Magnet Roll Bush

022K62850 Roller - Tracking Roll

022K70620 Roller - IIT Roll Image Input Terminal (IIT) document transport system. It is responsible for helping move documents through the scanning or input section of the machine

022K70630 Roller - Tension Roll

059K33820 Roller - Pressure Roll (REP 10.7)

059K36210 Roller - Manual Feed Roll

059K36230 Roller - Feed Roll

059K36240 Roller - RFC Take Away Roll

499W17062 Roller - Roller

019E45520 Saddle - Wire Saddle

035K82960 Seal - Toner Seal

019E19161 Sensors - Sensor Holder

020E15690 Sensors - Sensor Wheel

130E91010 Sensors - Full Toner Sensor (REP 9.5)

130K68990 Sensors - Exit Motion Sensor (Q10-3)

130K81230 Sensors - Toner Empty Sensor

130K87980 Sensors - RFC Air Sensor (Q7-18), Open Air Sensor (Q9-3) (Q9-3)

130K88860 Sensors - Open Left Cover Sensor (Q1-3)

130K88870 Sensors - Open Right Cover Sensor (Q1-2)

930W00112 Sensors - IITRegi. Sensor (REP 60.12)

006K23770 Service Parts - Auger (REP6.4.4)

022K70640 Service Parts - Upper Document Transport

022K72480 Service Parts - Xerox Part

062K15400 Service Parts - Cis

117E21380 Service Parts - Earth Wire

815E09000 Service Parts - DTS Plate

826E12370 Service Parts - Stud

930W00211 Service Parts - Tray 3 Pre Feed Sensor (C8045/55, C8070)

960K01870 Service Parts - Lpf I/F

960K08820 Service Parts - Side Triac PWB (SSR10-1), Center Triac PWB (SSR10-2)

068K27910 Shelf - Document Shelf

849E34990 Shelf - Document Shelf (REP 16.10)

014E96490 Spacer - Spacer

014E97200 Spacer - Spacer

003E65170 Stopper - Stopper

110E11230 Switch - Stand-by Switch (S1-1)

110K11380 Switch - Roll 1 Auto Cut Switch

110K91850 Switch - Exit Jam Switch (S10-1)

130K86451 Thermistor - Thermistor (RT10-1, RT10-2, RT10-3, RT10-4)

130E82881 Thermostat - Over Heat Thermostat (THS10-1)

130K62700 Trigger - Roll 1 Set Sensor (Q7-6), Roll 2 Set Sensor (Q7-12)

052K93680 Tube - Roll Paper Tube

005E88740 Wheel - Wheel

802K68320 Wing - Left Swing Cover (REP 16.2)

802K68340 Wing - Right Swing Cover (REP 16.6)
