Xerox parts list for 6705-Wide-Format Xerox 6705 Wide Format

055K28732 Baffle - Takeaway Baffle (PL10.8)

055K30133 Baffle - Upper Baffle

023E21500 Belt - Belt

423W73154 Belt - Belt (P/O PL1.1 Item 21)

033K94710 Blade - Metering Blade (REP 9.11)

033K94740 Blade - Cleaner Blade (REP6.4.1)

014E55930 Block - Block

014K82160 Block - Spring Block

014K82210 Block - RFC Takeaway Roll Block

117K36556 Cable - RFC Flat Cable

052K92220 Cartridge - Toner Pipe

017K93160 Caster - Caster

017K93170 Caster - Caster

121E20780 Catch - Catch Magnet (installation location: PL7.3)

121E84820 Catch - Catch Magnet

121E86350 Catch - Catch Magnet

121E89690 Catch - Catch Magnet

849E38520 Catch - Catch Magnet Bracket

101E15040 Chassis - Breaker Chassis (P/O Item 1)

005K07210 Clutch - Friction Clutch

121K34540 Clutch - (SCC) Manual Feed Clutch (REP99.1.1)

121K34890 Clutch - RFC Takeaway Clutch (REP1.1.1)

127K35823 Clutch - (SCC) Main Motor and Deve Clutch (REP1.2.1, REP99.1.1)

005E19270 Collar - Collar

913W02321 Connector - (SCC) Inlet Connector (REP99.1.1)

117K36421 Cord - BCR Cord

117K36451 Cord - Deve Bias Cord

117K36461 Cord - BTR Cord

117K36472 Cord - DTS Cord

802K76781 Cover - Rear Lower Cover (REP9.3.5)

037K90870 Cutter - (SCC) Cutter Assembly (REP10.2.1, REP99.1.1)

110K11370 Cutter - Cutter Interlock Switch (S1-7, S1-8)

802K67450 Developer - Developer Assembly (REP 9.10)

809E58190 Developer - Developer Tension Spring

110K10520 Drawer - RFC 1 Drawer Open Switch

809E36250 Extension - Extension Spring

960K08750 Filter - AC Filter PWB

019K06901 Finger - Finger

802E72150 Foot - Foot Cover

019E92900 Fuse - Fuser Stripper Finger

007P60934 Gear - Gear (Spur 40T)

499W14432 Gear - Pulley (32T)

038E31501 Guide - Turn Guide

038K88110 Guide Paper - Paper Guide

962K24220 Harness - Inlet Harness

962K24611 Harness - Sensor Wire Harness

110E10660 Heater - Paper Heater Switch

126E93151 Heater - (SCC) Center Paper Heater (AP/GCO: 200V) (REP99.1.1)

126K17751 Heater - (SCC) Center Heater Rod (Connector: White) (AP/GCO: 240V) (REP7.1.1, REP99.1.1)

126K17761 Heater - (SCC) Side Heater Rod (Connector: Blue) (AP/GCO: 240V) (REP7.1.1, REP99.1.1)

126K17771 Heater - (SCC) Sub Heater Rod (Connector: Red) (AP/GCO: 240V) (REP7.1.1, REP99.1.1)

020E98790 Idler - Idler Pulley

499W17061 Idler - Idler Pulley

110E97990 Interlock - Front Interlock Switch

815E08940 Interlock - Interlock Switch Actuator

003E84580 Knob - Knob

826E12421 Knob - Knob Screw

849E34160 Lamp - Lamp Bracket

003E56250 Latch - Left Latch

003E56260 Latch - Right Latch

127K31870 Motor - Fuser Drive Motor (MOT10-1) (REP 10.4)

127K33340 Motor - Feeder Motor (MOT8-1, MOT8-3)

960K01560 Motor - RFC Motor PWB

960K01872 PC Board - (Scc) Lph I/F Pwb (Rep4.1.2, Rep99.1.1)

029E35732 Pin - Pin

059E92390 Pin - Pinch Roll

105E16260 Power Supply - 3.5 Lvps 220v (Eo)

105E16280 Power Supply - 5b1,5b2 Lvps 220v (Eo)

105K20901 Power Supply - (Scc) Hvps (Rep8.2.1, Rep99.1.1)

007K85260 Pulley - RFC 2 Gear and Pulley

020E37560 Pulley - Drum Pulley

960K06221 Relay - (SCC) AC Relay PWB (REP8.1.2, REP99.1.1)

009E58670 Ring - Torsion Spring

013E19240 Ring - Bearing

013P60672 Ring - Bearing

013P61299 Ring - Bearing

413W11460 Ring - Sleeve Bearing

413W11660 Ring - Sleeve bearing (REP 90.17)

413W12350 Ring - Ball Bearing

413W75959 Ring - Powdered Metal Bearing

413W77359 Ring - Bearing

809E22970 Ring - BTR Spring

809E56630 Ring - Compression Spring

809E56640 Ring - Tension Spring

809E56650 Ring - Earth Spring

809E56800 Ring - Tension Spring

809E58220 Ring - Tension Spring

809E61120 Ring - Tension Spring

016E95410 Roller - Magnet Roll Bush

059K36241 Roller - RFC 2 Takeaway Roll

059K75970 Roller - Heat Roll (REP7.2.1)

059K76000 Roller - Regi Roll (REP2.1.4)

059K76010 Roller - Manual Feed Roll (REP2.1.3)

121K34532 Roller - Mag Roll (REP5.2.1)

035K82960 Seal - Toner Seal

020E15691 Sensors - Sensor Wheel

130E89260 Sensors - Exit Motion Sensor

130E91010 Sensors - Full Toner Sensor (REP 9.5)

130K70430 Sensors - H-Tra Jam Sensor

130K81230 Sensors - Toner Empty Sensor

130K87980 Sensors - RFC Air Sensor (Q7-18), Open Air Sensor (Q9-3) (Q9-3)

130K88870 Sensors - Open Right Cover Sensor (Q1-2)

930W00112 Sensors - IITRegi. Sensor (REP 60.12)

006K23770 Service Parts - Auger (REP6.4.4)

117E21380 Service Parts - Earth Wire

815E09000 Service Parts - DTS Plate

826E12370 Service Parts - Stud

930W00211 Service Parts - Tray 3 Pre Feed Sensor (C8045/55, C8070)

960K08820 Service Parts - Side Triac PWB (SSR10-1), Center Triac PWB (SSR10-2)

014E58570 Spacer - Spacer (thickness = 7 mm)

110E11230 Switch - Stand-by Switch (S1-1)

110K11380 Switch - Roll 1 Auto Cut Switch

962K98721 Thermistor - Heat Roll Thermistor 1,2, 3, 4 (REP7.3.2)

130E82881 Thermostat - Over Heat Thermostat (THS10-1)

130K62700 Trigger - Roll 1 Set Sensor (Q7-6), Roll 2 Set Sensor (Q7-12)

005E88740 Wheel - Wheel

802K68340 Wing - Right Swing Cover (REP 16.6)
