HP parts list for 870B7A Latex 730

Y0U21-67244 Belt - Belt and Tensioners for all HP Latex 700/700W and 800/800W Printers. It is a critical hardware component responsible for driving and maintaining the precise smooth movement of the printhead carriage assembly horizontally across the printing width.

Y0U21-67111 Ink Supply Station - Ink Supply Station PCA (Printed Circuit Assembly) for several models of HP Latex wide-format printers. For HP Latex models 630 700 800 models and similar.

870B9-67005 Motor - Service motor assembly

Y0U21-67005 Motor - Printhead cleaning roll motor assy

Y0U21-67006 Motor - Spit Roller Motor assy

Y0U21-67033 Motor - Vapor Curtain Motor assembly

Y0U21-67068 Motor - Substrate Advance Motor assembly

Y0U21-67072 Motor - Pinch wheel motor

Y0U21-67121 Motor - Scan Axis Motor Assembly

Y0U21-67167 Motor - Rewinder Motor Assembly

Y0U21-67168 Motor - Take-up reel motor assembly

Y0U21-67262 Motor - Drop detector and motor assembly SRV

M0E29-67062 Roller - 64-inch plotters Entry Roller Assy. Entry Roller Assy for HP Latex 700 800 560 630 630W and Stitch S500 Printers and compatible units.

171S2-67062 Service Parts - EE Printmech PCA SK

171S2-67097 Service Parts - Media Edge Holders Sunspot

171S2-67105 Service Parts - Differencial pressure sensors SF SRV

171S2-67106 Service Parts - Black Ink Tray w/ pump+gluer+syringe

171S2-67107 Service Parts - Yellow Ink Tray w/ pump+gluer+syringe

171S2-67108 Service Parts - Magenta Ink Tray w/ pump+gluer+syringe

171S2-67109 Service Parts - Cyan Ink Tray w/ pump+gluer+syringe

171S2-67110 Service Parts - Overcoat Ink Tray w/ pump+gluer+syringe

171S2-67111 Service Parts - Optimizer Ink Tray w/ pump+gluer+syringe

171S2-67112 Service Parts - Lgt Magenta Ink Tray w/pump+gluer+syri

171S2-67113 Service Parts - Lgt Cyan Ink Tray w/ pump+gluer+syringe

171S2-67115 Service Parts - Ink Supply Station w/o pwr distribution

171S2-67120 Service Parts - Curing Control PCA SK

171S2-67124 Service Parts - Differencial pressure sensors SF SRV

171S2-67125 Service Parts - Black Ink Tray w pump SF SRV

171S2-67126 Service Parts - Yellow Ink Tray w pump SF SRV

171S2-67127 Service Parts - Magenta Ink Tray w pump SF SRV

171S2-67128 Service Parts - Cyan Ink Tray w pump SF SRV

171S2-67129 Service Parts - Overcoat Ink Tray w pump SF SRV

171S2-67130 Service Parts - Optimizer Ink Tray w pump SF SRV

171S2-67131 Service Parts - Lgt Magenta Ink Tray w pump SF SRV

171S2-67132 Service Parts - Lgt Cyan Ink Tray w pump SF SRV

2RM82-67037 Service Parts - Pump motor with Gear train (w/o Cable) Denoted image3.replacement service part designed for HP large-format and production printers. It drives the service station's fluid pump mechanism.

2RM82-67039 Service Parts - Ids Pca HP Image Data System Printed Circuit Assembly (IDS PCA). HP Desingjet Z6 Z9+ Pro 64in Printer.

4UU94A Service Parts - HP 836 Optimizer Latex Printhead

4UU95A Service Parts - HP 836 Universal Latex Printhead

4UV95A Service Parts - HP 836 Black/Cyan Latex Printhead

4UV96A Service Parts - HP 836 Magenta/Yellow Latex Printhead

4UV97A Service Parts - HP 836 Lt Cyan/Lt Mag Latex Printhead

4UV98A Service Parts - HP 836 Overcoat Latex Printhead

69G27-67106 Service Parts - EE Curing Converter PCA

69G27-67181 Service Parts - Lubrication Felts Kit GD Oiler SRV

7QR88-67162 Service Parts - 2.4 Inline Checkvalve replacement SRV

870B7-67001 Service Parts - Output Platen 700/700W

870B7-67002 Service Parts - ISS structural parts

870B7-67004 Service Parts - Pinch Cam Supports SRV

870B7-67005 Service Parts - Commonly Used Screws SRV

870B7-67007 Service Parts - Vapor Collector Tubes SRV

870B7-67008 Service Parts - Vapor Collector Support SRV

870B7-67009 Service Parts - Right Entry Bracket SRV

870B7-67011 Service Parts - Output platen protector SRV

870B7-67012 Service Parts - Carriage Cover SRV

870B7-67013 Service Parts - Transmission cover SRV

870B7-67014 Service Parts - Lifting Mechanism Handle SRV

870B7-67015 Service Parts - Curing Lateral Covers 700/700W SRV

870B7-67016 Service Parts - Left Hub MO SRV

870B7-67019 Service Parts - Encoder spring holder SRV

870B7-67022 Service Parts - Edge Holders SRV

870B7-67023 Service Parts - Right Edge Holder and Static Platen SRV

870B7-67024 Service Parts - Removable Platen Springs and Clips SRV

870B7-67025 Service Parts - Optical Sensor SVS (SVS SRV) primarily used in HP Latex and DesignJet printers to ensure accurate print performance. This part is commonly used to replace the older less stable sensor design in HP Latex 700/800 series and Z-series printers to prevent errors caused by vibrations.

870B7-67026 Service Parts - Impinging Structure 730/730w

870B7-67027 Service Parts - Curing Control PCA SRV

870B7-67028 Service Parts - Print zone locker assembly SRV

870B7-67030 Service Parts - Right Edge Holder and Static Platen SRV

870B7-67032 Service Parts - Substrate Adv Roller BI SVS

870B9-67002 Service Parts - Vapor Collector Serv

870B9-67006 Service Parts - Service Station

870B9-67007 Service Parts - Lubrication Felts Kit GD Oiler SRV

870B9-67008 Service Parts - Carriage Complete Assy

870B9-67009 Service Parts - Vapor Conduction assy

870B9-67011 Service Parts - Vapor Condensation assembly

870B9-67012 Service Parts - Regen system pipe

870B9-67013 Service Parts - Deflector fan unit

870B9-67014 Service Parts - Deflector unit

870B9-67015 Service Parts - Pinch wheel module

870B9-67021 Service Parts - Inner Lights assembly

870B9-67023 Service Parts - MIMO Loading Table

870B9-67024 Service Parts - MIMO lateral covers

870B9-67025 Service Parts - Left Hub MI SRV

870B9-67040 Service Parts - Primer assembly

870B9-67041 Service Parts - Printheads Cover

870B9-67042 Service Parts - Left Cover

870B9-67044 Service Parts - Right Cover

870B9-67045 Service Parts - Service Station Door trims

870B9-67046 Service Parts - Service station door

870B9-67048 Service Parts - Platen Bridge

870C0-67001 Service Parts - SOL Sensor

Y0U21-67002 Service Parts - Primer assembly

Y0U21-67007 Service Parts - Optical Sensor (see image #2) SVS Optical Sensor SVS for HP Latex 700W Printer HP DESIGNJET Z6 PRO 64-IN PRINTER HP DESIGNJET Z9+ 64IN PRODUCTION PRINT HP DesignJet Z9+ Pro 64-in Printer HP LATEX 700W PRINTER 800 W PRINTER R530 Printer and similar models.

Y0U21-67012 Service Parts - Line Sensor

Y0U21-67013 Service Parts - Encoder strip and sensor 64

Y0U21-67015 Service Parts - Carriage Flex Cables

Y0U21-67018 Service Parts - Carriage Protector

Y0U21-67019 Service Parts - Carriage Protector assembly

Y0U21-67021 Service Parts - Carriage PCA

Y0U21-67022 Service Parts - Platens kit

Y0U21-67023 Service Parts - Advance Sensor

Y0U21-67024 Service Parts - Print zone locker assembly

Y0U21-67025 Service Parts - Vacuum fan assembly

Y0U21-67026 Service Parts - Vacuum rubbers kit

Y0U21-67027 Service Parts - Ink Collectors

Y0U21-67028 Service Parts - Ink Collector sensor

Y0U21-67029 Service Parts - Media Edge Holders Sunspot

Y0U21-67031 Service Parts - SOL Actuator

Y0U21-67032 Service Parts - Vapor Curtain Bar

Y0U21-67034 Service Parts - Curing Heater Fan assembly

Y0U21-67038 Service Parts - Lifting mechanism rubber stoppers

Y0U21-67040 Service Parts - Curing cables 700/700W

Y0U21-67042 Service Parts - Platen and Media Sensor Platen

Y0U21-67045 Service Parts - Carriage Rear Slider

Y0U21-67048 Service Parts - Curing Recirculation Cover 700/700W

Y0U21-67052 Service Parts - Lifting Mechanism Handle

Y0U21-67053 Service Parts - Lifting mechanism Gas Springs 700/700W

Y0U21-67054 Service Parts - Output Roller

Y0U21-67058 Service Parts - Hot flux fan

Y0U21-67059 Service Parts - Cold Flux Fan

Y0U21-67063 Service Parts - Regen Heater

Y0U21-67066 Service Parts - Cutter Module Kit Fit For HP Designjet 700 700W 800 800W and similar models.

Y0U21-67067 Service Parts - Cutter Guide Assembly

Y0U21-67069 Service Parts - Substrate Advance Roller

Y0U21-67070 Service Parts - Substrate Advance Roller Bushings - For the HP Designjet Z6 Pro Z9+ and Latex 630 630W 700W and 800W Printer

Y0U21-67073 Service Parts - Substrate advance roller adaptor

Y0U21-67074 Service Parts - Substrate presence sensor

Y0U21-67075 Service Parts - Substrate Input Platen assembly

Y0U21-67076 Service Parts - Substrate Input Plastic Adapter

Y0U21-67077 Service Parts - Right Entry bracket assy

Y0U21-67085 Service Parts - Carriage Cover

Y0U21-67088 Service Parts - Front Panel Button Speaker & Switches

Y0U21-67089 Service Parts - Front Panel assembly

Y0U21-67090 Service Parts - Front Panel PCA cover

Y0U21-67091 Service Parts - Front Window

Y0U21-67092 Service Parts - Window Sensor and Hinge

Y0U21-67094 Service Parts - Curing Lateral Covers 700/700W

Y0U21-67095 Service Parts - Top cover

Y0U21-67098 Service Parts - Rear Cover 700/700W

Y0U21-67099 Service Parts - Back Cover

Y0U21-67100 Service Parts - Rear Connector Cover

Y0U21-67101 Service Parts - Front Panel PCA

Y0U21-67102 Service Parts - Formatter PCA 700/700W

Y0U21-67105 Service Parts - Printmech PCA

Y0U21-67106 Service Parts - Printmench Extension PCA

Y0U21-67107 Service Parts - Power Board PCA

Y0U21-67114 Service Parts - Curing Power Distribution PCA

Y0U21-67115 Service Parts - Curing Control PCA

Y0U21-67116 Service Parts - Hard Drive

Y0U21-67117 Service Parts - Curing Converter PCA

Y0U21-67119 Service Parts - Cooling Fan Curing Converter

Y0U21-67122 Service Parts - Electrical Box Covers

Y0U21-67134 Service Parts - Empty Supply Frame 700

Y0U21-67149 Service Parts - Supply Frames Frontal Cover

Y0U21-67160 Service Parts - SAX components

Y0U21-67163 Service Parts - Footbrace assembly

Y0U21-67164 Service Parts - used across several HP DesignJet and Latex printers (such as the DesignJet Z6 Pro Z9+ XL 3800 and Latex 630 700W and 800W series)

Y0U21-67165 Service Parts - Vapor Curtain Handles

Y0U21-67166 Service Parts - MIMO Structure Bars w/ Spiders

Y0U21-67171 Service Parts - Transmission cover

Y0U21-67172 Service Parts - MI Right Structure assembly

Y0U21-67173 Service Parts - Right Structure and Extension

Y0U21-67174 Service Parts - Left Structure and Extension

Y0U21-67175 Service Parts - Diverter Roller

Y0U21-67178 Service Parts - Platen Bridge

Y0U21-67180 Service Parts - Right Side General Cabling

Y0U21-67181 Service Parts - Left Side General Cabling

Y0U21-67184 Service Parts - Trailing Cable data/pwr

Y0U21-67186 Service Parts - Right foot assembly

Y0U21-67187 Service Parts - Left foot assembly

Y0U21-67188 Service Parts - Drop Detector

Y0U21-67204 Service Parts - Static Platen 64in assy KIT

Y0U21-67205 Service Parts - Gauss Board

Y0U21-67206 Service Parts - Impinging cleaning kit

Y0U21-67211 Service Parts - Eebox Fan

Y0U21-67218 Service Parts - User Maintenance Kit

Y0U21-67221 Service Parts - Purge kit

Y0U21-67222 Service Parts - Output platen protector

Y0U21-67223 Service Parts - Media Loading

Y0U21-67225 Service Parts - Media Drive Assembly Tool

Y0U21-67231 Service Parts - Right lifter mechanism arm

Y0U21-67232 Service Parts - Media feed kit

Y0U21-67238 Service Parts - Impinging Structure 700/700w

Y0U21-67242 Service Parts - Grease Kit Side Wipe

Y0U21-67243 Service Parts - Left lifter mechanism arm

Y0U21-67246 Service Parts - Power supply unit 500W Sella

Y0U21-67247 Service Parts - E-box cables Sella

Y0U21-67255 Service Parts - Bias Spring Drive Roller SVC kit

Y0U21-67256 Service Parts - Mimo Transmission Hub Assy Srv

Y0U21-67259 Service Parts - 3 in spindleless hub SRV

Y0U21-67260 Service Parts - 2 in spindleless hub SRV

Y0U21-67269 Service Parts - IDS system repair

Y0U21-67271 Service Parts - Grounding Media Advance SK

Y0U22-67009 Service Parts - IDS cables 8 CS

M0E29-67061 Wiper - Wiper Roller Assy

HP Latex 730 (870B7A)

HP parts list for 870B7A HP Latex 730 Printer
